2014 NEW Arrival Hantek DSO8060 60MHz 5-in-1 Handheld Digital Oscilloscope DMM Spectrum Analyzer
Product Description
Product Features:
• Isolated level:1000V CATII,600V CATIII.
• High Bandwidth 150MHz Oscilloscope,1GSa/s sample rate, and 6000 Counts DMM with analog bargraph , and data recorder.
• Memory Depth;2M Single-channel;1 M Dual-channel
• High Refresh Rate (2500 frames)
• Large 5.6 inch TFT Color LCD Display,High Resolution(640*480), Dual-Window Design --More clear, More Detailed
• One-touch automatic setup optimizes the position, range, timebase, and triggering to assure a stable display of virtually any waveform
• Easy-to-use pop-up menu with built-in multi-language help system
• 23 Automatic Measurements
• Waveform Math: Add, Subtract, Multiply, and Divide
• Store and recall over
• Automatic cursor tracking measurements
• XY Mode
• Built-in FFT function converts a time-domain signal into its frequency components to measure harmonic content and distortion in systems
• Waveform Recorder to capture/replay input waveforms from CH1 and CH2 with a maximum record length of 1000 frames
• Pass-Fail function compares a stored waveform to an unknown input
• Average Mode for smoothing waveforms
• Square Wave Output (2V, 1kHz) for probe adjustment
• USB Host/Device 2.0 full-speed interface ,support removeable disk, LAN Optional ,Easy to control by PC or long-distance.
• Dimensions (mm):240(L)x165(W)x50(H), be carried easily.
Speciafications:
Package: Main body and Accessories
1PC HANTEK DSO1152S Handheld Isolated Oscilloscope
1pc Oscilloscope Bag
1pc USB cord
2pc Oscilloscope Probes
2pc oscilloscope Test leads
1pc CD
1pc Power Cord
