Specifications
HP-870K Dual Display digital multimeter Clamp On Meter
HP-870K Dual Display digital multimeter Clamp On Meter
Specifications
1.DC Voltage 400mV~1000V
2.AC Voltage 400mV~750V
3.DC Current 4000mA~30A
4.AC Current 4000mA~30A
Basic function
DC Voltage
Range |
Accuracy |
Resolution |
400mV |
1.2% of rdg+5digits |
0.1mV |
4V |
0.8% of rdg+5digits |
1mV |
40V |
10mV |
|
400V |
100mV |
|
1000V |
1.5% of rdg+5 digits |
1V |
AC Voltage
Range |
Accuracy |
Resolution |
Frequency |
400mV |
±(2.5% of rdg +15 digit ) |
0.1mV |
50~100Hz |
4V |
1.2% of rdg+15 digits |
1mV |
|
40V |
10mV |
|
|
400V |
100mV |
|
|
750V |
2.5% of rdg+15 digits |
1V |
|
DC Current
Range |
Accuracy |
Resolution |
4000mA |
3.5% of rdg+10 digits |
1mA |
30A |
3.0% of rdg+10 digits |
10m A |
AC Current
Range |
Accuracy |
Resolution |
Frequency |
4000mA |
3.5% of rdg+10 digits |
1mA |
50~60Hz |
30A |
3.0% of rdg+10 digits |
10m A |
Resistance 400Ω~40MΩ
Capacitance 40nF~100μF
Temperature -20 celsium degree~1000 celsium degree
Frequency 5.12Hz~100kHz
Duty Cycle 0.1%~99.9%
Express function
Display 3999
Range Select Auto
AC Leaker Current Test √
Auto Power Off √
Diode Test √
Continuity Buzzer √
Data Hold √
Back Light √
Relative Value √
Dual Display √
Jaw Caliber 21mm
General Features
Battery Type 9V(6F22)x1
