Specifications

--RS232/WG26/RS485/RJ45
--860Mhz~960Mhz
--15m read range
--450*450*120mm
--one year warranty

860Mhz~960Mhz 15 Meters Long Range Passive UHF RFID Reader with China supplier

 DESCRIPTION

JM-0703 is a high performance UHF RFID integrated reader&writer. It is designed upon fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, anti-counterfeit and industrial production process control system.

FEATURES

lSelf-intellectual property;

lSupport ISO18000-6B, ISO18000-6C(EPC C1G2) protocol tag;

l860~928MHz frequency band(frequency customization optional);

lFHSS or Fix Frequency transmission;

lRF output power up to 30dbm(adjustable);

l12dbi antenna optional with Reading distance up to 15 meter;

lSupport auto-running, interactive and trigger-activating work mode;

lLow power dissipation with single +9 DC power supply;

lSupport RS232, RS485, Wiegand interface;

PARAMETERS:

IP level	level 56
Protocol	ISO18000-6B, ISO18000-6C (EPC GEN2)
Frequency range	ISM, 902 to 928MHz (FCC) or ISM 865 to 868MHz optional (other frequency depends on customers' request)
Operating mode	FHSS
RF power output	0 to 30dBm, software configurable
Communication interface	RS232/485,Wergand 26/32/34, RJ45 (TCP/IP)
Input	1 triggering input
Reading range	10-15m
Output Power	30dbm (software can be adjustable)
Power consumption	≤2W
Material	ABS
Antenna gain	12dbits
Reading clue buzzer	Yes
Power consumption	12V(supply AC/DC)
Working temperature	-30~+80°C
Storage temperature	-30~+85°C
Humidity	20% ~ 95%
Size	450mm×450mm×45mm
Weight	6Kg (With bracket and packing)
Accessories	Power supply,RS-232,disk(SDK, Demo,User’s manual )
