Aluminium Alloy 800Lbs Indicator Electric Magnetic Door Lock

Aluminium Alloy 800Lbs Indicator Electric Magnetic Door Lock thumbnail-1
Aluminium Alloy 800Lbs Indicator Electric Magnetic Door Lock photo-1
US$ 12 - 14 MOQ: 100 Units
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Jemis
Model Number:
JM-380GF
Contact Supplier Request Quote Chat Now
Shenzhen Jemis Security Technology Company Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Jemis
Model Number JM-380GF

    Aluminium Alloy 800Lbs Indicator Electric Magnetic Door Lock


Product Description
Product 280KG/600lbs Electromagnetic Lock with LED and door position detection output
Lock Size 285Lx55Wx30H(mm)
Armature plate 180Lx38Wx11H(mm)
Holding Force 380kg (800Lbs)
Voltage: DC12V or DC24V (adjustable)
Current Draw 12V/500mA 24V/250mA
LED Red indicates the door is unlock, Green indicates the door is lock
Suitable for Wooden door , Glass door ,Metal door , Fireproof door
Suitable Humidity 0~90% (non-condensing)
Finishes for Shell Anodized aluminum & surface texture processing
Finishes for Magnetic Zinc
Finishes for Armature Zinc
Weight 2kg
Standard Packing

12pcs

Hot sell Model:



Model JM-60G JM-180AF JM-180GF JM-180GSF JM-280GF JM-280AF JM-280GFS
Voltage 12V/24V +10%
Current 300mA/DC12V 150mA/DC24 600/DC12V 480mA/DC12V 960mA/DC12V
300/DC24V 240mA/DC24V 240mA/DC24V
Max Straight 60kg(120Lbs) 180kg(300Lbs) 180kg(300Lbs) 180kg(300Lbs)*2 280kg(600Lbs) 280kg(600Lbs) 280kgx2(600Lbsx2)

direction pull
working -10~+55°c

Temperature
Moisture 0~95%
Durability 500,000 times
Weight 0.5kg 1.2kg 1.2kg 2.4kg 2kg 2kg 4kg
Dimension(mm) 80*35*19 170*35*21 190*32*21 340*35*21 250*42*25 231*41*24 500*42*25

Lock:
Dimension(mm) 65*33*11 130*33*9.3 130*33*9.3 130*33*9.3 180*38*11 180*38*11 180*38*11

Iron Block:
Suitable Door File cabinet,locker single Glass , single Glass , Double Glass , single Glass , single Glass , Double Glass ,

wooden, wooden, wooden, wooden, wooden, wooden,

Wardrobe fire doors fire doors fire doors fire doors fire doors fire doors
Installation visible visible invisible visible visible invisible visible



  Aluminium Alloy 800Lbs Indicator Electric Magnetic Door LockAluminium Alloy 800Lbs Indicator Electric Magnetic Door LockAluminium Alloy 800Lbs Indicator Electric Magnetic Door LockAluminium Alloy 800Lbs Indicator Electric Magnetic Door LockAluminium Alloy 800Lbs Indicator Electric Magnetic Door LockAluminium Alloy 800Lbs Indicator Electric Magnetic Door Lock
