Kyoritsu 4105A Digital Earth Resistance Tester
US$ 417 - 434
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
KYORITSU
Model Number:
4105A
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fast Shipping NEW DY-B23A DC Wheatstone Bridge, OriginalUS$ 350 - 400MOQ: 1 Piece -
MS2302 Digital Earth Ground Resistance Tester MeterUS$ 90 - 120MOQ: 1 Piece
-
MS2301 High Accuracy Clamp Meter Digital Earth Resistance TesterUS$ 450 - 500MOQ: 1 Piece
-
MS2308 Intelligent Advanced Earth Resistance Tester,clamp Earth Resistance Tester With Usb CommunicationUS$ 1,600 - 1,800MOQ: 1 Piece
-
MS5215 High Voltage Digital Insulation Resistance Tester 5000V 3mA, Temp.(-10-70C) MeggerUS$ 1,430 - 1,500MOQ: 1 Piece
Place of Origin
Japan
Brand Name
KYORITSU
Model Number
4105A
Display Type
Digital Only
Operating Temperature
-10~50
Dimensions
105(L) x 158(W) x70(D)mm
kyoritsu 4102A Earth Testers With a Suitcase analogue display
| The latest circuit design permits the instrument to operate with the minimum of influence from earth voltage and earth resistance of auxiliary earth spikes. | |
| • | Dust and drip proof. (designed to IEC 529 IP54) |
| • | Earth resistance value can be read directly from the scale. |
| • | Designed to meet IEC 61010-1 safety standard. |
| • | Capable of measuring earth voltage. |
| • | Small and lightweight. Shock resistant new case material. |
| • | 2mA measuring current permits earth resistance tests without tripping earth leakage current breakers in the circuit under test. |
| • | Lead wire connection to C and P terminals and proper auxiliary earth resistance can be checked by "OK" lamp. Lead wire connection to C and E terminals is good when "OK" lamp is illuminated. |
| Measurement Ranges |
Earth Resistance: 0~12 Ω/0~120 Ω/0~1200 Ω Earth Voltage [50,60Hz]: 0~30V AC |
||||
| Accuracy | Earth Resistance: ±3% of full scale Earth Voltage: ±3% of full scale |
||||
| Overload Protection | Earth Resistance: 276V AC for 10 seconds across 2 of the 3 terminals Earth Voltage: 276V AC for 1 minute |
||||
| Safety Standard | IEC 61010-1 CAT.III 300V Pollution Degree 2, IEC 61557 | ||||
| Applicable Standards | IEC 60529 IP54 | ||||
| Withstand Voltage | 3700V AC for 1 minute | ||||
| Power Source | R6P (AA) (1.5V) × 6 | ||||
| Dimensions | 105(L) × 158(W) × 70(D)mm | ||||
| Weight | 600g approx. | ||||
| Accessories |
7095A (Earth resistance test leads) × 1set (red-20m, yellow-10m, green-5m) 8032 (Auxiliary earth spikes) × 1set 7127A (Simplified measurement probe) × 1set R6P (AA) × 6 Neck strap Instruction Manual
|
