HP7000 1000 Volt Tester Clamp On Ground Resistance Tester

Name: HP7000 1000 Volt Tester Clamp On Ground Resistance Tester
Brand: HoldPeak
SKU: 130766901
Availability: InStock

US$ 1 - 300 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

HoldPeak

Model Number:

HP7000

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name HoldPeak

Model Number HP7000

Specifications

HP7000 1000 volt tester Clamp On Ground Resistance Tester

1.Non- contact-type to measure earth resistance, safe and fast.

2.Date Hold
3.Manual/Auto Power Off

*Range*	*0.01-1200Ω*
*Resolution*	*0.001Ω*
*Sound and light alarm*	*"beep - beep - beep -" alarm sound, Flashing alarm symbol, By AL key to open, close, set*
*LCD*	*4-digital LCD, 47×28.5mm in length*
*Boot-strap*	*Self-testing in 0.5 second*
*Relative Humidity*	10%*-90*%
*Explosion-proof mark*
*Shift*	*Automatic Shifting*
*External Magnetic Field*	*Less than 40A*/m
*External Electric Field*	*Less than 1V/m*
*Single Measurement Time*	*0.5 second*
*Resistance Measurement Frequency*	*More than 1KHz*
*The Measured Current Frequency*	*50/60Hz Automatism*
*Storable Measurement Data*	*99groups*
*Setting* *Range* *of Resistance Alarm Critical Value*	*1-199 Ω*
*Protection Level*	*Double insulation*
*Structural Feature*	*In the jaw way CT*
*Power Source*	*6VDC (4 ×5# alkaline battery)*
*Span of Jaw*	*28mm*
*Net Weight*	*1160g (including batteries)*
*Dimension*	*285mm long, 85mm wide,56mm thick*
