Specifications
HP5104 Insulation Resistance Tester
HP5104 Insulation Resistance Tester
Specifications
1.Auto Range
2.Insulation resistance testing
3.Phase testing
4.Voltage testing
5.LCD background light
Insulation Tester
Function:
Auto Range
Insulation resistance testing
Phase testing
Voltage testing
LCD background light
New model applied
Testing Voltage
250/500/1000/2500V
Insulation Resistance:
0.1M~20GΩ ±(3%+5)
Basic function
Range
Testing Voltage 250/500/1000/2500V
Insulation Resistance 0.1M~20GΩ±(3%+5)
AC Voltage 700V±(2%+5)
Max.Display 1999
Range Select Auto Range
Function Symbol Displau √
Data Hold √
Low Battery Warning √
LCDbackground light √
Overload Protection Resistance 280V AC/DC for10sec
Overload Protection Voltage 300V AC/DC for1Min
Safety Standard IEC61010-1CAT.III300V Pollution LeveIIIIEC61557
Standard Accessory Linex2pcs,lron Stickx1pair,User'sManualx1pcs,Carrying case
Battery Type AA1.5V*8
Dimension 190×155×75mm
Weight 900g
Ctn Size 530x310x400mm
Q'TY / Ctn 20PCS
GW/NW 15/14Kg
