2.4Ghz Long Range Active RFID Reader Module with battery Replaceable Active Tag JM-1704





2.4Ghz De largo alcance lector de RFID activa JM-1704





General Description:
It is a High Performance Active 2.4-2.48G directional reader for long range operation with High speed identification, long distance, low power consumption

Features:
     100 pcs tags/s(tag ID number)
        200 pcs tags will be read at same time
        Real-time operation system
        Frequency power can be adjusted by software
        Reading distance 2-100 meter
        2.45GHZ active RFID reader long range

Area of Application:


        Personnel management: quick attendance administration, conference signature system, student safety note system, security patrol system.

        Cargo management: storage and data collection, system, moving goods control and trace, container automatic identification.

        Prevention management: personnel positioning, tracing and goods anti-fake and test.

        Public management: city traffic intelligent platform, vehicle control and operation, train automatic numbering

       Transportation management: road, railway management, and container transfer control tracking management.



Functions

Working Frequency

2.4-2.48G

Reading Speed

100 pcs tags/s(tag ID number)

Bumping capability

200 pcs tags will be read at same time

Reading Distance

Greater than 80 meters

Frequency Power

≤30 dBm , can be adjusted by software

Reading Sensitivity

-90dBm

Microwave Communication

CRC16

Antenna

directional

Electronic Magnetic In EMI

10V/m 0.1-1000MHz AM

Reliability

MTBF ≥ 70000 hours

Connecting Ports

Working Voltage:

9-12V DC(MAX 30mA)

Interface

RS-232

Wiegand Interface:Wiegand26&Wiegand34Supported

RS-485

10/100M Ethernet(for Customized Model only)

Operating Environment

Operation

-20°C - +70°C

Storage

-40°C - +85°C

Physical Parameter

Dimension

227mm*227mm*60mm

Weight

1.8Kg

Accessories

Power Supply

AC110-220V/DC+12V

Cables

Power Cable

RS232 Serial Cable

Brackets

Pole Mount Adapter

Software Pack (Optional)

API Software Development Kits complete with C#Sample Program



Battery Chang-enable Tag JM-1832

2.4Ghz De largo alcance lector de RFID activa JM-1704

Specifications

1.active tag for 2.4G Reader
2.frequency:2.4GHz-2.5GHz
3.reader distance:5-100m meters
4.Reading way: read-only way

It is source from RFID electric label component

FRID electric label circuit board,install on the inner housing, has waterproof feature

ABS plastic housing, joint by the ultrasonic

Battery: use one CR2032 batteries,lifespan is 6 months in theory

Applications: access control, time attendance, hotel management, transportation, library and campus



Technical Data

1. Working frequency: 2.4GHz-2.5GHz

2. Working way:2.45G active mode

3. Emitting power:<1mW

4. Reading way: read-only way

5. Reading distance:5-100 meters

6. Battery changing: support battery changing

7. Working lifespan in theory : more than half a year

8. Static working current: <3uA

9. Maximum working current:<15mA

10.Communication rate:two way 2048Kbit/s

11. Working voltage:3V (CR2302 button battery)

12. Bumping capability: have strong anti bumping capability, can read card synchronous more than 200 pieces for one second

13. Dimension : 75mm×40mm×5.5mm

14. Working temperature:-20°C -75°C

15. direction for use



User attention

1. Please let the products be insolated in the sun,it will increase the battery's consumption, shorter its lifespan

2. Do not fall the device, because its housing is made of ABS plastic

3. Do not put the device on fire, otherwise the battery will explore



How to change the battery

1.please open the battery cover in the back softly with the toothpick

2. Please press the battery with the toothpick until the battery pop up

3. Changing battery that is batteries are needed to be changed

4.When changing battery, please make clear the the positive and negative charges ( the negative charge face down

5. Cover the battery cover well
