12V/24V LCD Solar Charge Controller
*Visual LCD graphic symbol
*Battery low voltage protection
*Overload & short circuit protection
*Automatic identification system voltage level
*Adjustable charge-discharge control parameters
100% brand new and high quality
Visual LCD graphic symbol, brief key operation.
Automatic identification system voltage level, intelligent PWM charge mode.
Adjustable charge/discharge control parameters, settable operating modes of loads.
Multiple selection of battery.
Battery over temperature protection, low voltage/reverse polarity protection.
*Over-load and short-circuit protection.
*With dual USB output.
*Multiple selection of battery
*Brief key operation
*Intelligent PWM charge mode
*Settable operating modes of loads
*Battery over temperature protection
*Battery reverses polarity protection
*Color: Blue & black
*Material: Plastic
*Rated Voltage: 12V / 24V (Auto Switch)
*Max. Charge/Discharge Current: 10A, 20A
*Max. Solar Panel Input Voltage: less than 50V
*Stop Charge Voltage: 14.7V/29.4V
*Low Voltage Recovery: 12.2V/24.4V
*Low Voltage Protection: 10.5V/21.0V
*USB Output Voltage/Current: 5V 2A
*No Load Loss: less than 10mA
*Temperature Compensation: -3mV/Cell/Centigrade
How to use it ?
Open the top cover of the controller and connect the wire with terminals follow the diagram on the cover of it
1) Firmly and correctly connect the "+", " poles of the battery to the corresponding ports of the controller (the third and the forth one from the left). When load indicator light flash once and will light after 30 seconds, which means that the connection is correct, and you can continue finishing following connection, otherwise the controller will be damaged
2) Firmly and correctly connect the "+", " poles of the solar panel to the corresponding ports of the controller (the first and the second one from the left). The wrong connection will damage the controller
3) Firmly and correctly connect the "+", " poles of the load to the corresponding ports of the controller (the fifth and the sixth one from the left)
Note:
The controller should be connected to the battery first
1. Please carefully check and confirm the voltage of the components before connecting
2. The rated current of Solar panel and load must be less the than the rated current of controller
●Package size:14.2x8x4cm g.w.:187.1g
●Package including:
1 x User Manual
●For online wholesale order:Item will be shipped within 3~5 days after payment.
●For OEM order:Item will be shipped within 15 days after initial payment is received.
