Home > Instruments & Meters > Electronic Instrument > Clamp Meter > UNI-T UT233 Digital Power Clamp Meter 3 Phase Electronic Meter
UNI-T UT233 Digital Power Clamp Meter 3 Phase Electronic Meter
US$ 180 - 200
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Uni-Trend
Model Number:
UT233
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CENTER-210 AC Clamp MeterUS$ 146 - 168MOQ: 1 Piece -
CENTER-202 Digital Clamp MeterUS$ 116 - 132MOQ: 1 Piece
-
ETCR9100B-H/L Voltage Clamp MeterNegotiableMOQ: 1 Piece
-
Multifunction High Sensitivity Leakage Current Clamp Meter DMM MASTECH MS2010BUS$ 200 - 230MOQ: 1 Piece
-
DY1300 Clamp-on Ground Resistance TesterUS$ 650 - 700MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Uni-Trend
Model Number
UT233
Display Type
Digital Only
Measuring Current Range
40A/100A/400A/1000A
Measuring Voltage Range
15V/100V/300V/600V
Operating Temperature
-50C-1000C
Dimensions
303 x 112 x 39 mm
Weight
601g
Specifications
UNI-T UT233 Digital Power Clamp Meter 3 phase electronic meterUNI-T UT233 Digital Power Clamp Meter 3 phase electronic meter free shipping
SPECIFICATIONS
| Basic Functions | Range | Best Accuracy | |||
|---|---|---|---|---|---|
| AC Voltage | 15V/100V/300V/600V | (1.2%+5) | |||
| AC Current | 40A/100A/400A/1000A | (2%+5) | |||
| Active Power | 0.01kW-600kW | (3%+5) | |||
| Apparent Power | 0.01kVA~600kVA | (4%+5) | |||
| Reactive Power | 0.01kVAr~600kVAr | (4%+5) | |||
| Power Factor | 0.3~1 | (0.02+2) | |||
| Phase Angle | 0C~360C | 1 | |||
| Frequency | 20Hz~500Hz | ||||
| Active Energy | 1~9999kWh | (3%+2) | |||
| Temperature | –50C~1000C |
||||
| Special Functions | |||||
| Auto Ranging | |||||
| Single-phase 2-wire | |||||
| 3-phase 3-wire | |||||
| 3-phase 4-wire | |||||
| Phase Rotation Test | |||||
| True RMS | AC Voltage or Curren | ||||
| Calibration Feature | |||||
| Data Logging | 99 | ||||
| Max/Min Mode | |||||
| Data Hold | |||||
| USB | |||||
| Display Backlight | |||||
| Full Icon Display | |||||
| Sleep Mode | |||||
| Low Battery Display | |||||
Input Impedance for ACVoltage Measurement |
≥10MΩ | ||||
| Max. Display | 9999 | ||||
GENERAL CHARACTERISTICS
| Power | 1.5V Battery (LR16) × 4 |
| LCD Size | 46 mm x 42 mm |
| Product Color | Red and Grey |
| Product Net Weight | 601g |
| Product Size | 303 x 112 x 39 mm |
| Standard Accessories | 4pcs of Test Lead, Batteries, English Manual, 4pcs of Alligator Clips, USB Interface Cable, Software, Tool Box |
| Standard Individual Packing | Gift Box |
