CENTER-222 Mini Clamp Meter, Clamp Meter Tester, AC CLAMP METER

CENTER-222 Mini Clamp Meter, Clamp Meter Tester, AC CLAMP METER thumbnail-1
CENTER-222 Mini Clamp Meter, Clamp Meter Tester, AC CLAMP METER photo-1
US$ 129 - 145 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CENTER
Model Number:
CENTER-222
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name CENTER
Model Number CENTER-222
Display Type Digital Only
Measuring Current Range .
Measuring Voltage Range .
Measuring Resistance Range .
Measuring Capacitance Range .
Measuring Inductance Range .
Operating Temperature .
Dimensions 187x50x29mm
Weight 210g

CENTER-222 mini clamp meter, clamp meter tester, AC CLAMP METER

CENTER-222 mini clamp meter, clamp meter tester, AC CLAMP METER

Specifications

Pocket size
Sampling rate: 2 times/sec

CENTER 220 MINI AC CLAMP METER



CENTER 220 is our low cost mini clamp series. 220 is a current probe with read out. 221 is added with voltage and continuity functions. 222 is an AC/DC clamp meter.



Key Specifications/Special Features:

  • Pocket size
  • Display: 3-1/2, 4 digital liquid display
  • Sampling rate: 2 times/sec
  • Data hold function
  • Jaw opening diameter: 25mm
  • Peak hold capture time: 10ms



Function Range Resolution Accuracy
ACA 20A~600A 0.01A~1A ±2%rdg+5dgts





Model



220



221



222



223



AC

AC

AC/DC

AC

True RMS









Clamping diameter

25 mm

25 mm

25 mm

12.5 mm

Backlit LCD









Measurement









Current











AC

Range

0.01 to 600 A

0.01 to 600 A

0.01 to 600 A

1mA to 100.0 A


Accuracy

2% rdg + 5 dgts

2% rdg + 5 dgts

2% rdg + 5 dgts

2% rdg + 10 dgts

DC

Range





0.1 to 600.0 A

1mA to 100.0 A



Accuracy





2% rdg + 5 dgts

2.5% rdg + 10 dgts

Voltage











AC

Range



0.1 to 600 V

0.1 to 600 V

0.1 to 600.0 V


Accuracy



1.5% rdg + 5 dgts

1.5% rdg + 5 dgts

1.5% rdg + 5 dgts

DC

Range





0.1 to 600.0 V

0.1 to 600.0 V



Accuracy





1% rdg + 2 dgts

1% rdg + 2 dgts

Ohm



0.1 to 200.0 Ω

0.1 to 200.0 Ω

1 Ω to 10K Ω

Hz











Current











Voltage









Continuity



≤100 Ω

≤100 Ω

≤100 Ω

Diode test









WATT









Functions









Peak





YES

YES

Hold

YES

YES

YES

YES

Zero





YES

YES

Max.









REL









Auto power off

YES

YES

YES

YES

Electrical safety rating

300V CAT III

300V CAT III

300V CAT III

300V CAT III

Battery

2 x AAA 1.5V

2 x AAA 1.5V

2 x AAA 1.5V

2 x AAA 1.5V

Dimensions & Weight

187x50x29mm/210g

187x50x29mm/210g

187x50x29mm/210g

202x50x29mm/180g
