TCP/IP, RS485, Wiegand in/out biometric card 2.4'' color LCD fingerprint access control
JM-F151 is an affortable fingerprint access for office environments, it applies mass reliable import components and
the most advanced fingerprint arithmetic in the world. Its design strictly follows domestic standard of security products,
product must pass the rigid aging test before being sent to customers. It is suitable for office access control and
enterprises’ internal access control, it has the time attendance function as well. It’s stable and safety, so it could satisfy
the requirement for both fingerprint validation of access control system and identity verification.
Model |
JM-F151 |
LCD Screen |
2.4 inch TFT (320*240) Color Screen |
Fingerprint Sensor Resolution |
500DPI (Optical sensor) |
Hardware Platform |
REALANDR ZDC2911 |
Algorithm Version |
REALANDR RSFv5.1 |
CPU |
ARM926EJ CPU, Running Frequency: 200MHZ |
Communication |
TCP/IP, RS485, USB Memory Disk |
User Capacity |
1,000 (optional to 2,000 or 3,000) |
Records Capacity |
100,000 |
Software OS |
XP/Win2003/Vista/Win7/Win8 (32bit / 64bit) |
Identification Time |
< 1 S |
Authentication Method |
Fingerprint/ RFID Card (125Khz)(could customize Mifare card)/Password |
Language |
Chinese / English / Spanish/Portuguese/ German (could customize others) |
Bell |
Built-in timing bell(can connect to external timing bell) |
Access Control Interface |
Wiegand26/34, Door Lock, Siren, Release Button(can connect 2 groups), Doorbell, Door Sensor |
Professional Access Function |
Open door by multilevel verification, anti-pass back |
Power |
DC 12V/2A |
FRR |
<1% |
FAR |
<0.00001% |
Operating Mode |
Off-line/On-line |
Authentication Mode |
1:1, 1:N |
Operating environment |
Operating Temp: 0°C-50°C, Humidity:80% |
Certificates |
CE, ,FCC,UL ,Type Inspection Report of Chinese Police Product |
|
Dimension(L*W*H)mm
|
Terminal - 181*91*36mm Package – 246*164*71mm |
Weight |
Terminal – 0.48 Kg Package – 0.812Kg |
