Mini Concrete Pump for Sale

FOB Price

US$ 1 - 20,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Electric
Place of Origin	Henan, China	Brand Name	BETTER
Model Number	HBT	Power(W)	22kw
Weight	2500kg	Dimension(LWH)	338012701245
Certification	ISO CE	Warranty	1 Year
After-sales Service Provided	Engineers available to service machinery overseas

Mini concrete pump for sale

Product Description

Adoption of advanced S-valve,can meet the needs of fine stone concrete conveying.

Wear plate and cutting ring are made of anti-wearing horniness alloy,they have long service lives.

High output pressure can satisfy the requirement of high-rise building and construction of long distance transmission.

Equipped with centralized lubrication system,ensure the service life of the rotating part.

The electrical box is equipped with wired remote control handle,easy to operation.

Technical parameters

Concrete Pump		HBT15-08S
Theoretical maximum output		15m3/h
Concrete pumping pressure	High pressure	8Mpa
	Low pressure	4.2Mpa
Pump distance	Vertical conveying height	110m
	Horizontal transmission distance	300m
Max.aggregate sizes		25mm
Motor power		22kw
Concrete slump		12-23cm
Concrete cylinder diameter×stoke		Φ120×550
dimension		3380×1270×1245(mm)
Weight		1480kg

Application

1.Conveying concrete for floor heating,mortar,high-rise building.

2.Transport all kinds of plain concrete,fiber reinforced concrete in engineering construction.

3.Transfer of greening soil in ecological environment construction.

4.The pressure grouting of all kinds of foundation pile.

5.The highway construction transport.
