DY2201D Automotive Meter

Name: DY2201D Automotive Meter
Brand: DUOYI
SKU: 130757069
Availability: InStock

Shenzhen Graigar Technology Co., Ltd.

US$ 100 - 120 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

DUOYI

Model Number:

DY2201D

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name DUOYI

Model Number DY2201D

Measuring Resistance Range 200/20K/200K/20MΩ

Dimensions 200*85*38 mm

Specifications

DY2201D Automotive Meter

accurate mS-Pulse Width function to test on-time of fuel injectors
RPM measurement for automotive engines with 1 to 8 Cylinders using the Inductive pickup
Patented mis-operation prevention: terminal shutter interlock mechanism, patent code: ZL 01 21 5021.5
Measurement of ms pulse width, Duty, DWELL and RPM with clamp sensor
Measurement of motor dwell angle 0°~120°(3/4/5/6/8 CYL)
Measurement of motor speed 500RPM - 10000RPM(3/4/5/6/8/ CYL)
Feature rich design DMM with up to 11 functions
Continuity buzzer / Data hold / Auto Power off
Heavy duty rubber holster

Automotive Multimeters

MODEL	DY2201D
Duty	0.1 ~ 99.9% ±(1.5%+2)
Ignition Frequency	0.1Hz ~ 100KHz ±(2.0%+2)
Pulse Width	0.1 ~ 999.9ms ±(3.0%+5)
DC V	2/20/200/1000 V ±(0.5%+3)
AC V	2/20/200/700 V ±(1.0%+3)
DC A	20m/200m/20 A ±(1.0%+2)
AC A	20m/200m/20 A ±(1.5%+2)
Resistance	200/20K/200K/20M Ω ±(1.0%+3)
Temperature	-40°C~1000°C ±(1%+3)
Party cycle	1%~90%
TACH	500-10000RPM 3/4/5/6/8CYL ±(1.5%+5)
DWELL	0°~120° 3/4/5/6/8CYL ±(1.5%+5)
Diode test	yes
Transistor test	yes
Continuity buzzer	yes
Data Hold	yes
Auto Power OFF	yes
LCD MAX. Count	1999
terminal sockets with automatic blocking system	yes

Power	6F22(9V)
Product Size	2008538 mm
Product Net Weight	700g
Standard individual packing	gift box
Standard Quantity per Carton	20 pcs.
Measurement of Standard Carton	480370335mm (0.059 CBM)
Gross weight of Standard Carton	18kgs
