This inverter welder dc arc welding machine,inverter welding machine,mma welding machine,electric welding machine ,arc welder,inverter welder has the following characteristics
1. Compact in volume, light in weight and power saved.
2. Easy to arc initiation, resistance to interference, good force adjustment.
3. Stable welding current, low welding spatter.
4. Good welding result, deep welding pool, high intension.
5. Protection for over voltage, over current.
6. Automatic voltage pulsation compensation capability.
7. Applicable for various acid and basic welding electrodes.
This device is applicable for welding of such materials as stainless steel, metal alloy steel, carbon steel, copper and other non-ferrous.
| Parameters | ARC120 | ARC140 ARC140P |
ARC160 ARC160P |
ARC180 ARC180P |
ARC200 ARC200P |
| Input voltage | 50/60hz(1ph) | 50/60hz(1ph) | 50/60hz(1ph) | 50/60hz(1ph) | 50/60hz(1ph) |
| 230V±10% | 230V±10% | 230V±10% | 230V±10% | 230V±10% | |
| Input current | Max.18A | Max.20A | Max.22A | Max.24A | Max.29A |
| No-load voltage | 75V | 75V | 80V | 80V | 80V |
| Eiffciency | 85% | 85% | 85% | 85% | 85% |
| Input power | Max.3.9kw | Max.4.2kw | Max.4.8kw | Max.5.3kw | Max.6.4kw |
| Output voltage | 24.8V | 25.6V | 26.4V | 27.2V | 28.0V |
| Output Current range | 10-120A | 10-140A | 10-160A | 10-180A | 10-200A |
| Duty cycle | 60%:100A 35%:120A |
60%:110A 35%:140A |
60%:120A 35%:160A |
60%:140A 35%:180A |
60%:160A 35%:200A |
| Welding rod | 1.5-2.5mm | 1.5-3.2mm | 1.5-3.2mm | 1.5-4mm | 1.5-4mm |
| Suitable board | 1.5-3mm | 1.5-4mm | 1.5-6mm | 1.5-10mm | 1.5-11mm |
| Protection class | IP21 | IP21 | IP21 | IP21 | IP21 |
| Weight | 3.4kg | 3.4kg | 4.5kg | 4.7kg | 4.9kg |
| Dimensions | 29x13x19cm | 29x13x19cm | 29x13x20cm | 31x13x20cm | 31x13x21cm |
We,YongKang Songshi Electric Appliance Factory, specilized in produce portable MMA inverter welders for many years in china, adopt advanced IGBT inverter technique, with the outstanding virture of smaller size(31x13x21cm,N.W 4.9kgs)but larger output current(200A)for a long time steadily welding, you can easily take it to anywhere for widely use.
We supply the inverter welders with the high quality which can be compared with italy ones, but with much lower price.
