3g wireless home security alarm camera system two way talk function

Specifications

3g gsm video camera security alarm
1.Video call alarm
2.two-way communication
3.Remote monitoring
4.FCC.CE

3g wireless home security alarm camera system two way talk function



Features:

1.Setup by USB cable or wireless keypad,1.3 Megapixel camera, remote 3G mobile phone monitoring
2.With PTZ, Pan 0-360 degree and Tilt 0-90 degree rotation
3.12pcs IR LED, 8 meters night vision to ensure the system can work in the night.
4.With backup battery to ensure the system continue to work when AC power off
5.With built-in speaker and microphone,can remote speak and talk with the camera.
6.SMS notification if any sensor is triggered
7.Dial-in to remote control the camera to watch monitoring video via 3G phone
8.5X Digital Zoom function to make you see clear image on your 3G phone.
9.Remote control the camera to arm/disarm/turn on siren/turn off siren/2-way talking/digital zoom etc during 3G video call.
10.Entry/Exit time delay
11.SD card video recording function: video auto recording bofore video call, remote contorl camera to record video into the SD card
12.World-wide USE W-CDMA 3G Format,full band.
13.MMS alert: MMS picture from the camera will be sent to your mobile after system triggered.
14.can work with 20 alarm accessories and 5 remote control like door sensor,PIR sensor,smoke sensor,etc.
15.Voice instruction to guide you after you answer the call and further operate the system.
16.Areas without 3G signal,system will turn to 2G mode, auto dial out phone numbers and send MMS.
17.Auto dial 6 group phone numbers prestored,send SMS/MMS alert after system triggered.
18.Can connect wired siren which will go off after system triggered to make loud sound and scare the intruder.

How it works:

1.Somebody intrude your house and trigger the sensors
2.Triggered sensors will send signals to the 3G camera
3.The 3G camera will auto dial out preset 3G number,wired-connected siren will go off,send out SMS or MMS alert.
4.Your 3G mobile phone will ring and receive SMS/MMS message.
5.After you answer the call from the 3G camera,you will see video from the camera on your phone.
6.You can remote rotate the 3G camera,turn off/on siren,listen in,two-way talk,arm/disarm,zoom in/out,etc.

Parameter:
Network:
Provider: WCDMA USIM Card
Operating frequency:
Triple-band HSDPA/UMTS 850/1900/2100 MHz
Quad-band EDGE/GPRS/GSM 850/900/1800/1900 MHz



Alarm Feature:
RF frequency: 315/433.92MHz
Work with wireless door/window contact, PIR motion sensor, smoke/gas detector, glass break detector etc.



IR Night Vision:
12 LED
8 meters night vision



Video & Audio:
Video format: 3GP
Resolution: 1280 X 960
Audio format: H.324
Built-in microphone & speaker for 2-way talking



Memory Storage:
SD card
Capacity support: Max 4G

User Interface:
3G Mobile phone



Power Supply:
Input: AC 110-240V, 50/60Hz;
Output: DC12V
With built-in 3.7v/12v rechargeable lithium battery

Ergonomic Design:
Ceiling-mount kit
Pan(0-360°)/Tilt(0-90°) rotation
ABS cover
Indoor usage
