Hot product CRS300 BOSCH CRDI common rail diesel injector tester
The function of CRS300 BOSCH crdi common rail diesel injector tester
for CR high pressure pumps is to provide the desired signal to drive the solenoid in the pump being tested. CRS300 common rail Tester can used for testing following pumps: BOSCH CP1,CP2,CP3,DELPHI,SIEMENS, DENSO HP2 AND HP3. It has the functions to test the Electromagnetic and Piezoelectric injectors.
It also can test 6 common rail injectors in one time.
Design Features
* Modulated driving signal to ensure the safety of the solenoid of the CR pump
* Adjustable duty cycle for the driving signal
* Short circuit protection for the output circuitry of the solenoid driving signal
* Measure and LCD display rail pressure
* To test if the CR injector is still function, To connect a CR injector to a high pressure fuel source by a high pressure fuel line and to the CR tester by harness. The tester is set to continuous injection mode. The CR injector is in normal condition, if it is capable to inject fuel under the driving signals by the tester.
* To test injector spray atomization, To connect a CR injector to a high pressure fuel source by a high pressure fuel line
and to the CR tester by harness. The tester is set to single injection mode to allow observing the nozzle spray pattern to judge if the nozzle is normal or orifice plugged.
* Checking the Injectors return oil and injection oil.
|
Testing following pumps |
BOSCH CP1,CP2,CP3,DELPHI,SIEMENS, DENSO HP2 AND HP3. |
Functions |
test the Electromagnetic and Piezoelectric injectors. |
|
Can test 6 common rail injectors |
in one time. |
CRS 300 tester connect with BC3000 test bench
We also have other model test bench,please point the model and check:
| Diesel Injection Pump test bench | Common Rail System Test Bench | Common Rail Tester and Electronic Pump Tester |
| 12PSB | PQ1000 | CR1000 |
| MINI12PSB | BCS300 | CR2000 |
| BC3000 | BC-CR708 | CR2000A or CRS3 |
| BCS619 | BC-CR819 | EUI/EUP tester and CAM BOX |
| BCS815 | CRS708 | VP44 tester |
| BC2001 | CRS709 |
Q1: What is your Trade Terms?
A: FOB CFR CIF EXW DDP and DDU
Q2: What is your payment terms?
A: T/T,Western Union ,PayPay,Escrow and L/C
Q3: What is your delivery time?
A: Test bench is 7-10 working days,tester, diagnostic tool and injectors,we have stock.
Q4: Why should I choose your product?
A: We can provide you the best quality and the most competitive price ,and we have our own engineer,if you have any requirements you can contact us directly~
