most popular products BC-CR708 common rail diesel fuel injection pump test bench price
BC-CR708 common rail diesel injector pump test benches is mainly test for common rail pump and Injector. Also it is continuous fuel delivery analysis computerised measuring system for conventional and new diesel injection systems. The electronic fuel delivery measuring system is compulsory for modern diesel injection system testing. It guarantees a high level of reproductivity of the measured Value.
1. System Application:
The system is suitable for detection of BOSCH, DENSO, DELPHI and
SIEMENS common rail pump and injectors. Such as CP1, CP2.CP3, HP3 series injector pump and the type of Electromagnetic injectors, It also can test 6 common rail injectors in one time.
2. Technical parameters
1, Main motor speed |
0-4000 r / min can be adjustable. |
2, Motor power |
7.5KW, 11KW, 15KW, 18.5KW optional. |
3, Fuel Injector open voltage Control range |
12V, 80V, 150V Control accuracy: phase adjustment |
4, Injector opening frequency Control |
0-1000HZ Control accuracy: 1HZ |
5, Fuel Injector Hold Time Control |
0-65535us |
|
6 Delivery Oil CountControl Control accuracy |
0-1000 times 1 times |
|
7, Fuel pressure control Control Control accuracy |
0-2000bar 1bar |
8, Electronic power |
3 PHASE 380V or 3 PHASE 220V |
3,Optional function:
1,Test piezo injector function.
2,Test HP0 pump function.
3, With Bosch DRV VALUE
4,Check the pump flow
>>>we also have other model number test bench for injector and pump ,pls point the model name and then check details
| diesel fuel injection pump test bench | common rail injection pump test bench | tester and heui |
| 12PSB |
CRS708c(can add EUI/EUP&Cambox) CRS709c(can add EUI/EUP&Cambox |
CR1000 (200USD with piezo function) |
| BC3000 | BC-CR708(most competitive price) | CRS3 (can add piezo testing function ) |
| BC2001 | CRS200 | VP44 pump tester |
| BC2001PLC | CRS300(can add VP37 VP44 EUIEUP) | VP37 pump tester |
| BCS619 | eps200 | EUI EUP&Cambox |
| BCS815 | BCS200 | V3V4V5 pump tester |
| BCS300 | s60h | |
| BCS205 TEST EBNCH | PQ1000(only 1300USD per set) | Heui hydraulic test bench |
Taian Beacon Machine Manufacturing Co., Ltd. is the leading manufacture in diesel injection pump test bench
and turbocharger balancing machine in China ,our products already sold to more than 100 countries .
Our products including common rail injector test bench ,common rail injector tester (CRDI),
diesel injection pump test bench EUI/EUP tester cam box ,Denso ECD-V3 ,V4, V5 pump tester ,
PT cummins pump and injector tester ,common rail tools and spare part .
Welcome you to visit our factory and cooperate in the future.
>>>Welcome to contact with us !!!
