top selling products RYQ-16 turbine rotor balancing machine
The separate style
Industrial control computer 19 "LCD color screens
WidowsChinese and English system double choice
With AM-2000 general microcomputer balance measuring systemAutomatic program-controlled amplifier module
Any workpiece scaling function, arbitrary Angle clamp compensating andworkpiece information storage
Qualified quantity showed that adjustment function measurement cycleSignal amplifier amplification and manual adjustment,
signal self-check, automatic
diagnosis
Vector graphics, waveform and out of balance, shows at the same time
Surplus balabcing g and unbalanced torque, the g cm, g mm can choose to display
RYQ-16 hard bearing horizontal dynamic balancing machine Optional function
1. Angle tracking function
2. automatic stopping after complete measurement
3. the model RYQ-16 and below this model, Automatic positioning function after parking
4. vector angle decomposition function
Feature:
universal hard backing dynamic balancing machine
Features: the series is hard bearing horizontal dynamic balancing machine,using the wheel backing, rings with drag ,the popular style is two-speed electric - driven,
“A” is variable-frequency electromotor plus inverter speed, industrial control computer data processing, color screen real-time shows the value of the amount of unbalance
,phase and real-time rotational speed, bases have adopted the overall foundry, stability is good. It is widely applied in engine, wind motor, blower,
diesel engine and auto parts andother range, It can balance and measure on single side, double side and many test sides, fit for axial, plate and gravity out-stretching roller.
It has characterstics of high efficency, correct precision, direct display, good quality, convenient maintenance and so on, the soft has both common work piece and standard
roller special functions, avoid demarcateequipment non-automatically for customers who use other hard support balancing machine measure system,
and you can choose many measure method and function, it can realize to input parameter, preview, test, save results, type, use chinese menu to operate, man-machine conversation,
auto prompting.
>>>OPTIONAL FUNCTION
1. Angle tracking function
2. Automatic stopping after complete measurement
3. The model RYQ-160A and below this model,Automatic positioning function after parking
4. Vector angle decomposition function
Technical data :
| Model | RYQ-16 |
| Mass of Workpiece (kg) | 0.3-16 |
| Max.diameter of workpiece (mm) | φ500 |
| Distance between two support bearing(mm) | 60-600 |
| Bearing diameter of axle in scope (mm) | φ5-36 |
| Balancing speed min(r/mm) | 400-5000 |
| Min. Achievable residual Unbalance (g.mm/kg) | ≤0.5 |
| Unbalance reduction ratio(%) | ≥90 |
| Drive power (kw) | 0.18 |
Beacon machine packing :
>>>Welcome to contact with us
