stainless steel security barrier supermarket entrance access control turnstile manual swing gate with smart card
- Power: AC220V; 50HZ
- Driver Mode: DC motor 140W / 24V
- Dimensions: 1900mm x 900mm x 1085mm
- Lane Width: 900mm
- Communicate Interface: TCP / IP
- Communicate Distance: 1200m
- Passing Speed: 40people /minute (N/O); 20people / minute (N/C); the data is empirical value, it need to depends on the response time of users’ optional access control system.
- Service Life: 5 millions continuous opening and closing
- Open and Close Time: 1 second
- Equipment Identification Ability: the distance of two people is over 130mm
- Numbers of Control system support infrared sensor: max. 8 pairs infrared sensors
Optional Part
- Can be customized the lane width
- Can choose controller system supported Infrared numbers : 4 ~ 8 pairs
- Able to use other material for housing, such as 316 stainless steel etc…
- Prevent Channel using other color
- Remote Control Board
- Integration of Various Kinds of Access Control Management System
Working Mode
- A-SD1 series Swing Gate has different working mode in passing direction A or B control.
- Passing Freely: open automatically when the infrared sensors detected the pedestrian.
- Locked All the Time: the direction is locked all the time, and the pedestrian can not pass through.
- Authorized to Pass: accomplished remote control though contacted various kinds of access control management system
- Release when the power is interrupt, the passing channel is released locking status after the power is interrupted, the pedestrian can be passing freely, avoid scare.
Equipment Composition
- Housing is using 1.5mm AISI-304 wire drawing of stainless steel,
- Made slop / open hole at the top of cylinder, can be built-in access control system in the inner space
- Channel status indicated that is able to built-in slop of the top of cylinder
- Organic glass for panel of gate
- The top of stainless steel board can be opened as to maintenance port.
- Cylinder was designed circular arc.
- Built-in infrared sensor in the side of housing.
- Electromechanical combination / electronic controller was built-in in the inner housing
Product Description
- SST-KB223 is a new style barrier gate, can be provide speed, secure and high-efficiency bi-directional barrier gate
- The product is using authorized mode to control and limit entry and exit, and using the complicated anti-following tracking control technology, able to judge quickly and correctly if someone is following, and strictly prevented entry of non-authorized people. To accomplished efficient management of pedestrian, and achieve safety function of barrier gate.
- The control technology of products is in the lead of the same products.
- Unique design, perfect control technology, valued and artistic outlook design, to be best choice for high flow and strictly safety needed places like government agency, office building, hotel and enterprises office building, etc…
