security bi-directional pedestrian access control barrier gate and swing barrier turnstiles
1.
1 |
Power |
AC220C±10V,50HZ |
2 |
Operating Temperature |
-15°C-60°C |
3 |
Access Width |
≤700mm |
4 |
Passing Speed |
50 persons/min(IC Card) |
5 |
Motor |
140W/24V |
6 |
Motor Speed |
1600R/Min |
7 |
Communication Distance |
≤1200M |
8 |
Input Connection |
+12V Level Signal or Pulse Wide>100ms Pulse Signal,Current>100ms |
9 |
Communication Connection |
RS485 |
10 |
Material |
SUS304,thickness 1.5mm |
11 |
Running Life |
5--8 Million(Continuous Opening and Closing Operation) |
12 |
Colour |
SSB(US32D)-Stainless Steel Brushed / Powder Coating(Optional) |
13 |
Applications |
Subway Station, Hoverport, Tourism Sports,Exhibition, Swimming Hall, Residence Area |
2.
Equipment Composition
- Housing is using 1.5mm AISI-304 wire drawing of stainless steel,
- Made slop / open hole at the top of cylinder, can be built-in access control system in the inner space
- Channel status indicated that is able to built-in slop of the top of cylinder
- Organic glass for panel of gate
- The top of stainless steel board can be opened as to maintenance port.
- Cylinder was designed circular arc.
- Built-in infrared sensor in the side of housing.
- Electromechanical combination / electronic controller was built-in in the inner housing
Security
Anti-fraud single-user throughput
Access control: entry, exit or bidirectional use
Sturdy rotating obstacle: all-welded construction
Anti-climbing structure
Mechanical locking
Economics & Safety
Smooth, silent and ease of use
Orientation pictograms for intuitive process and high throughput
Choice of free or secure passage in the event of a power failure
Emergency key for the mechanical unlocking of obstacle
3.
4.
5.
Customer services oriented.
Reply your inquiries within 12 hours.
Professional staffs answer any questions .
Customized design ,OEM & ODM are available.
Distributors or agents in special policies supports.
1. Providing the most professional solution as soon as possible according to your requirements.
2. Competitive and reasonable price with high quality products and advanced technology.
3. Passionate and professional sales makes a wonderful team.
4. Veteran technician solves all your problems.
5. Quickest delivery and best aftersales service.
6. One-stop procurement service is available.
Thanks for your view, if you are interested in our products, please kindly contact us by following information:
Tel: 86-755-29783835
Mobile: 86- 18925270403
Skype: szsstc1
