Specifications
1,RFID ID/IC card2,weight:75kg
3,material:304 # stainless steel
4,Customize Optional
5,Fingerprint applied
RFID access control automatic swing barrier gate/turnstile barrier swing gate
Swing gate
1.Description:
Integrating mechanism, electronics and micro-processor advanced technologies.The swing barrier is a improvement of intelligent tripod turnstiles.Equip various card-reading machines with hi-performance security protection SW to realize real-time warning and clever LED counter display guide passers .it balance pedestrian intelligent control and management.
Swing turnstile designs with tailored stainless steel make its elegance-looking,durable and anti-oxidation .Considering unique requests,we built-in standard electrical interface to best-fit customer easier using magnetic card,barcode,ID&IC cards integrated .This system provides civilized,well-organized pass management and meantime its prohibit illegal persons entry&out .
2.Technical Parameters:
1 |
Power |
AC220C±10V,50HZ |
2 |
Operating Temperature |
-15°C-60°C |
3 |
Access Width |
≤700mm |
4 |
Passing Speed |
50 persons/min(IC Card) |
5 |
Motor |
140W/24V |
6 |
Motor Speed |
1600R/Min |
7 |
Communication Distance |
≤1200M |
8 |
Input Connection |
+12V Level Signal or Pulse Wide>100ms Pulse Signal,Current>100ms |
9 |
Communication Connection |
RS485 |
10 |
Material |
SUS304,thickness 1.5mm |
11 |
Running Life |
5--8 Million(Continuous Opening and Closing Operation) |
12 |
Colour |
SSB(US32D)-Stainless Steel Brushed / Powder Coating(Optional) |
13 |
Applications |
Subway Station, Hoverport, Tourism Sports,Exhibition, Swimming Hall,Residence Area |
3.Functions and Features :
1. Self-checking function.
2. Working types:
2.1,bi-direction card reading;
2.2.one direction card reading and another prohibited;
2.3,one direction card reading and another free pass. Working types can be set in the control board.
3. Automatic turnstiles arm drop automatically when power off ;Arm recover its position automatically when power on.
4. Arm open&close time can be set by user in control boards
5. Manager can set pass time in control boards.
6. Flap barrier automatic alarm when illegal pass until passenger get an authorized card.
7. Swing barrier is RS485 interface for long-distance control.
8. Human safe: optical & mechanical anti-impact.Optical sensor detect passenger position.100% avoid passenger hurt during in passing . If arm meets any obstacle, arm stop working immediately .
9.LED display passengers numbers.
10. Direction display guide passenger go or stop.
11. Control software regulate authorized passengers numbers.
12. Stable running with low- noise.
4.Wire Connection Diagram
5.Multi-occasion Applications
6.Variety:
7.Standard Packages
8.Recommended Products
9.Our services
Customer services oriented.
Reply your inquiries within 12 hours.
Professional staffs answer any questions .
Customized design ,OEM & ODM are available.
Distributors or agents in special policies supports.
Thank you for your view!
Tel: 86-755-29783835
Skype: szsstc1
