MLC517C Static Torque Sensor for Measuring Rotary Force Torque

MLC517C Static Torque Sensor for Measuring Rotary Force Torque thumbnail-1
MLC517C Static Torque Sensor for Measuring Rotary Force Torque photo-1
US$ 190 - 245 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Manyyear
Model Number:
MLC517C
Contact Supplier Request Quote Chat Now
Manyyear Technology Company Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Manyyear
Model Number MLC517C

MLC517C Static torque sensor for measuring rotary force torque

Product Description

Features

Model: MLC517C

Category: torque sensor

Range: 0~2000,3000,5000Nm

Dimension: D70*238mm

Material: alloy steel

Apllication: Static torque measurement, motor torque, engine torque, combustion engine torque, fan torque, viscometer

, the pump torque, the gearbox torque, torque wrench

Characteristics: Static torque sensor, viscometer torque sensor, motor torque sensor, engine torque sensor, combustion engine torque sensor, fan torque sensor, the pump torque sensor, the gearbox torque sensor, wrench torque sensor

Torque sensor is the precision measuring instruments to measure torque,revolving speed and the power of the mechanical.

Product characteristics

Resistance strain for sensitive components and integrated circuit consisting of integrated products, high precision, stable and reliable performance, wide measuring range.

Static torque measurement, both ends are key links, easy installation and use.

application

1,Rotating power equipment such as motor, engine, engine output torque and power of detection;

2,Fan, water pump, gear box, torque wrench, torque and power of detection;

3,Railway locomotive, automobile, tractor, airplane, ship, mining machinery, the torque and power of detection;

4,Can be used in the sewage treatment system in torque and power of detection;

5,Can be used in the manufacture of viscometer;

6,Can be used in the laboratory, test department, in the process industry and process industry production monitoring and quality control;



Technology



SPEC

Range:

0~2000,3000,5000Nm

Response frequency:

100μS

Rated output:

1.0~2.0 mV/V

Insulation resistance:

2000 MΩ/100VDC

Comp. precision

±0.1; ±0.3; ±0.5%F.S

Input resistance:

700±10/350±10Ω

work temp.:

-35~+80℃

Output resistance:

700±5/350±5Ω

Temp. compensation :

20~+60℃

Zero point:

0~±1%F.S

Temp. effect at zero:

±0.1%F.S/10 ℃

Safe overload:

120%F.S

Work voltage:

12 VDC

Water proof:

IP65/66



Product Dimension

Product dimension

 MLC517C Static torque sensor for measuring rotary force torque

Pressure Connector

 NA

Electric Connector

 NA

Packaging & Shipping

Product photo

MLC517C Static torque sensor for measuring rotary force torque



Packing Reference

MLC517C Static torque sensor for measuring rotary force torque



Our Services

24Hr for response time.

5-7days for sample time.

15-25days for delivery time.

12 months for quality assurance time.

ODM, OEM support
