MPT423 Antisepsis Liquid Level Transmitter

Name: MPT423 Antisepsis Liquid Level Transmitter
Brand: MANYYEAR
SKU: 130662009
Availability: InStock

US$ 150 - 240 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

MANYYEAR

Model Number:

MPT423

Manyyear Technology Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name MANYYEAR

Model Number MPT423

MPT423 antisepsis liquid level transmitter

Product Description

Features

MPT423 ultra antisepsis digital level transmitter

Model: MPT423

Category: level sensor

Range: 0-50m H2O

temperature: ,-20~+125c

signal output: mv/v, 0-5vdc,4-20mA,Hart,Rs485

Application: corrosively liquid level measure, corrosively water level measure, sea water level measure

Characteristic: ultra antisepsis liquid level sensor, anti-corrosion oil level transmitter

Technology

Technology parameter:
capability range	0 ~0.5 ~5 ……50 m
pressure type	Gauge pressure, Absolutely pressure
signal output(mA/v)	mv/v, 0-5vdc,4-20mA,Hart,Rs485
Full load output(mV)	30~60~120
Zero point output(mV)	≤20
Precision	0.1, 0.2, 0.3
sluggish repeat (nor-linearity)(%FS)	≤0.1, ≤0.2, ≤0.3
excursion at zero point (%FS/4h)	≤0.1, ≤0.2, ≤0.3
temperature excursion(zero & delicacy)(%FS/ºC)	≤0.01, ≤0.02, ≤0.03
long term stability(%FS/year)	≤±0.1;≤±0.3
execute voltage(VDC)	24v (9~36v)
temperature compensate(ºC)	0~+80
work temperature(ºC)	.-30~+120
Overload(%)	300
life	>1X108pressure cycle(25ºC)
load resistance (Ω)	R=(U-12.5)/0.02-RD U=POWER SUPPLY,RD=wire resistance
response time(ms)	≤1
measure medium	compatible with Fluorin4 ethane medium
Film	ceramics
House	Fluorin4 ethane
connector thread	Submersible , fission, flange
explosion proof grade	ExibⅡCT6
