Help CenterSaw Blade Balancing Machine YLD-5
Related Products
Specifications
balancing machinesaw blade balancing
saw blade balancing machine
single plane balancing
computer display
Warranty period:
Life-time warranty. Any problem caused by our party within one year from the date of shipment, we will provide free spare parts for the repairment. After one year, we can provide the spare parts, but the user should pay for the related cost, including cost of the spare parts, delivery cost etc.
Technical Data:
Model |
Workpiece weight (Kg ) |
Workpiece diameter (mm) |
Balancing speed (r/min) |
Min. achievable residual unbalance (G.mm/kg) |
Unbalance reduction Ratio (%) |
Motor power (kw) |
Speed adjusting form |
YLD-5 |
0.1-5 |
500 |
900 |
≤ 3 |
≥90 |
0.37 |
Variable frequency Motor |
Features:
YLD series vertical balancing machine fits for balancing adjustment for parts with disc shape such as fan, pressure plate, flywheel, brake disc, ring blower, impeller, arrester, saw blade, pulley. Adopt industrial computer in measuring system. Digital or screen displays rotate speed, measured value, phase and amountof unbalance showing in “g” directly. Simple operation, straight display, adopt electromagnetic sensor, featured in large output, reliable performance and excellent stability.
