Specifications
transparent solar panelOur products bear IEC, TUV, UL, MCS, CQC, KIER, CE, PV CYCLE membership etc.
1 transparent solar panel.
2 Three consecutive cloudy or rainy days.
From hundreds of watts to tens of kilowatts of solar integrated family application system, GREENTECH Solar can always meet your changing needs. Whether it is a simple DC load (DC lighting, electric water heaters, etc.) or a variety of AC load (Refrigerators, washing machines, televisions, air conditioners), we can provide you with professional system configuration to ensure the system reliable and affordable. The system is particularly suitable for families who advocate green power and environmental protection or live in remote mountainous areas without grid system.
Normal parameter | ||
Mode |
GS-F-6KW |
|
Output power |
6KW/every day |
|
Working Days |
3 consecutive cloudy or rainy days |
|
Work temperature |
-30°C~+60°C |
|
Protection grade |
IP 65 |
|
Use Region |
This configuration is suited to use in the regions where the average daily Irradiation at the lowest average radiation month is about 3KW/m2. If the average daily irradiation is higher or lower than 3KW/m2, the configuration should be adjusted. We can provide efficient products according to the use region. |
|
Power resource | ||
Power resource |
reliable PV modules(solar panel) |
|
Cell technology |
mono-crystalline or poly-crystalline silicon |
|
the maximum power at STC |
2400W |
|
Energy storage | ||
Energy storage |
deep discharge sealed lead-acid battery |
|
Battery number |
6 |
|
Nominal voltage |
12V |
|
Rated capacity |
250Ah |
|
Protection |
over charge and over discharge protection |
|
Use life |
3 years at least |
|
Controller | ||
Controller |
Solar energy intelligent specialized controller |
|
Control mode |
switch on/off by light and time |
|
Controller & Inverter | ||
Controller & Inverter |
Solar energy intelligent specialized Controller & Inverter |
|
Output wave |
Pure sine wave |
|
Output voltage |
AC110/220/230V |
|
Output frequency |
50HZ/60HZ |
|
Precision of output voltage |
±3% |
|
Precision of output frequency |
±0.1% |
|
False output wave of AC |
<3% |
|
Overload ability |
120%, 30 seconds |
|
Invert efficiency |
>90% |
|
Load for example:
Name of Load |
Power(W) |
Quantity |
Working Time per Day (H) |
Color TV |
150 |
2 |
3 |
Computer |
100 |
2 |
3 |
Energy-saving lamp |
20 |
5 |
5 |
Electric Kettle |
1000 |
1 |
0.5 |
Microwave ovens |
1000 |
1 |
0.5 |
Refrigeratory |
50 |
1 |
24 |
Washing machine |
300 |
1 |
1 |
Rice cooker |
1000 |
1 |
1.5 |
If you want to get more information please ask me feel free, hope we could give you best support in near future.
