320W Poly Crystalline Solar Panel, PV Module, for Solar Power Plant With TUV, IEC, CE, CEC Certified

320W Poly Crystalline Solar Panel, PV Module, for Solar Power Plant With TUV, IEC, CE, CEC Certified thumbnail-1
320W Poly Crystalline Solar Panel, PV Module, for Solar Power Plant With TUV, IEC, CE, CEC Certified photo-1
US$ 1 - 320 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GH
Model Number:
GH037
Contact Supplier Request Quote Chat Now
Zhejiang Ganghang Solar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name GH
Model Number GH037
Material Polycrystalline Silicon
Size 156*156MM
Number of Cells 6*12PCS
Max. Power 320w

Specifications

285w solar modules pv panel
a grade solar cells
CE IEC,CEC TUV approved
short delivery delay time
25 years life spam

285w  Solar modules pv panel
a grade solar cells
CE IEC,CEC TUV approved
short delivery delay time
25 years life spam

Poly Solar Panel 320W
Brand:GANGHANG

Packing:Carton and Pallet
Certificate:TUV, VDE, CE, IEC

Poly Solar Panel 320W


Product Description

1. Solar panel/solar module/PV module/produced with high conversion effeciency, which purchased from Q-CELLS, CONERGY, ERSOL;
2. High quality of TPT, EVA, Tempered glass, aluminum frame to laminate solar panels and waterproof junction box and label;
3. With long lifetime of 25-30years, 5-10years warranty with and stable characterstics and performance;
4. We laminate solar panels from 5W-280W, with mono crystalline and poly crystalline solar cells.
5. We have TUV, ISO 9001/14001, CE, CEC certificate and so on.

Model

320W

Cells size (mm):

156*156

Cells per module:

6*12

Module size (mm):

992*1956*50

Power tolerance:

+/-3%

Nominal peak power(WP):

320

Nominal voltage(V):

45.3

Nominal current (A):

8.92

NOCT:

45+/-2degree

Voltage temperature coefficient:

-0.33%/degree

Current temperature coefficient:

+0.05%/degree

Power temperature coefficient:

-0.23%/degree

Open circuit voltage (Voc):

 46.2

Short cirsuit current(Isc):

8.95

Conversion efficiency:

18%

Operating temperature:

-40 to+85degree

Max system voltage:

1000V DC

320W Poly crystalline solar panel, PV module, for solar power plant with TUV, IEC, CE, CEC certified320W Poly crystalline solar panel, PV module, for solar power plant with TUV, IEC, CE, CEC certified320W Poly crystalline solar panel, PV module, for solar power plant with TUV, IEC, CE, CEC certified
