Specifications
Grid-off/tie solar power systemHome Solar Power Systems-
Grid Tie & Off Grid Solar Power Installation
solar power solution
Household Solar Energy System on-grid or off-grid Details:
solar power solution
1) lower cost for high effiiciency;
2) installed easily
3) Pure sine wave output;
Grid-off/tie solar power system
Home Solar Power Systems-
Grid Tie & Off Grid Solar Power Installation
solar power solution
- Household solar energy power supply system
- Solar panel: mono or poly
- Battery: lead-acid or gel
- Inverter: quasi-sine wave
1. Front glass 3.2mm think
2. Electric classfication Safety class II, Application class A
3. MC4 plug system
4. IP65
5. Positive power tolance up to +3%.
1.Poly solar panels 280w
2.100% TUV standard flash test
3.CE,TUV,UL certificate
4.25 years warranty with quality insurance
100% TUV standard flash test poly solar panels 280w with best price
1.What is 100% TUV standard flash test?
Flash test machine with TUV standard reference solar panel,all Propsolar Panel is tested with 100% TUV standard or standard higher than TUV standard
In the market,not all solar panel is real tested with TUV standard,Flash machine reference panel is not TUV standard,so the power is 2%-3% less than TUV standard
2.Descprition:
PS-P672 Series solar panel is connected in series by 72 pieces of 156mm×156mm Poly Crystalline silicon cells. PS-P672 Series solar panel includes 245W, 250W, 255W, 260W, 265W, 270W, 275W, 280W, 285W,290W, 295W.
3.Characteristics
1)Manufactured according to international quality and Environment Management
System (ISO9001, ISO14001)
2)High efficiency crystalline silicon solar cells
3)High transmission Iow iron tempered glass, strong mechanical resistance
4)Anti-ageing EVA and excellent anti-climate back sheet
5)Anodized aluminum frame improves load resistance capabilities for heavy wind loads.
6)Standard waterproof junction box
7)High endurance to different weather
8)Good and friendly package with less transportation and storage space.
4.Warranty
1)10 years limited manufacturing warranty
2)12 years for 90% of warranted minimum power
3)25 years for 80% of warranted minimum power
5.Electric Characteristics
CELL TYPE |
156 X 156 POLY SOLAR CELL |
||||||||||
ITEM |
245W |
250W |
255W |
260W |
265W |
270W |
275W |
280W |
285W |
290W |
295W |
Maximum Power(Wp) |
249.9 |
254.9 |
259.9 |
264.9 |
269.9 |
274.9 |
279.9 |
284.9 |
289.9 |
294.9 |
299.9 |
Open circuit Voltage (Voc) |
42.4 |
42.8 |
43.3 |
43.5 |
43.8 |
44.3 |
44.6 |
44.9 |
45.1 |
45.3 |
45.5 |
Short circuit Current (Isc) |
7.60 |
7.65 |
7.75 |
7.90 |
8.05 |
8.15 |
8.25 |
8.40 |
8.55 |
8.70 |
8.85 |
Maximum Power Voltage (Vm) |
34.9 |
35.1 |
35.4 |
35.5 |
35.7 |
36.0 |
36.2 |
36.3 |
36.4 |
36.5 |
36.6 |
Maximum Power Current (Im) |
7.02 |
7.12 |
7.20 |
7.32 |
7.42 |
7.50 |
7.60 |
7.71 |
7.83 |
7.95 |
8.07 |
