Cut Oil Circuit Car GPS Tracking Device WT1 Vehicle GPS Device
GSM/GPRS/GPS Tracker
Global smallest GPS tracking device application:
A nti-theft of the vehicle/heavy equipment etc.
P rotection of the child/elderly/disabled/pet etc.
P rovide peace-of-mind for businessman.
P ersonnel management.
C overt criminal tracking.
| Specifications : | |
| Items | Specification |
| Work voltage | DC 9V to 36V |
| Operation Temp. | -20°C to +70°C |
| Storage Temp. | -40°C to +85°C |
| Relative Humidity | 5% to 90% |
| power consumption | Average power consumption <1W; power-saving state <300mW |
| Host dimensions | 85*66*27mm |
| Host weight | 120g |
| Backup battery | 800Mah |
| GSM Module | SIMCOM |
| GPS Module | U-blox |
| Battery protection | Anti-200V power supply reverse; battery voltage is 36V high-voltage protection |
| Frequency | GSM/GPRS 850/900/1800/1900MHz |
| GPS performance | Receive Channels:50channels;cold start:32S;warm start:32S |
| Hot start:1S;GPS sensitivity:-160dbm;GPS accuracy:<10m | |
| I/O | Input : ACC , Door detection , SOS Power input ; the Reversible detected; Out put : stop engine output ; |
| Functions | |
| Tracking | Tracking in real time ,speed and mileage statistics,Geo-fencen setup etc. |
| Abnormal state prompt | Includes device breakdown ,cut power cable ,geo-fence alerts etc . |
| Configured remotely | Configure kinds of parameters,including IP,Center number,monitor parameters etc. |
| Control remotely | Stop engine remotely via platform or sms |
| SMS setting | Could use mobile phone to setup GPS,or we could ask engineers to fix all of parameters in advance .when you receive the devices ,just connect everything ,then they could work on your system automatically without send any commands to active. |
| Cut power line alarm | thermostability backup battery ,will be triggered while the power line is removed |
| Dual mode positioning | When GPS signal is poor ,the device will switch to base station location |
| Movement alarm | When device connect with ACC,after ACC is off,the device will enter fortification status to achieve movement alarm. |
| Memory data log | Will save gps datas on memory cards once devices move into blind areas |
| APP Tracking | Support to track the cars/Motorcycle via android / IOS mobile phone |
| Standard packing | GPS unit; GPS/GSM antenna ; power wires & SOS ; box ,user manual book |
| Optional accessories | backup battery , relay . |
FAQS :
1. How do track vehicles ?
You could use mobile phone or monitoring system(platform) to track and monitor the vehicles . We have APP tracking that support to install on Android mobile phone ,or you could use monitoring system to track them via computer directly .
2. If use your monitoring system to track the vehicles ,should we pay fees for them ?
We provide free system for you to track them in the first year .
3. How can we track the vehicles on android mobile phone ?
We will provide one APK software to you to install on your android mobile phone .
4. Will you provide free samples for testing ?
We don't provide free samples ,all of samples need to pay first ,then we will send them to you within 24 hours .
5. How could you make a new orders ?
For samples orders, ,you could pay them by Paypal or Western Union . For bulk orders ,you could pay via bank (T/T) .
6. How can we trust you ?
We are one of gold member of alibaba, all of information of our company has been approved by Alibaba ,. And we have already exported to all over the world for many years .we make friends with all of clients . Friendship first ,business second is our purpose .
If you still not trust us ,you could ask anyone of your friends here in China to come to visit our factory ,then you decide to start a orders later ..
7. How will you deliver the goods to us ?
We always send the goods to our clients via DHL/UPS/EMS/TNT express . If you have any agents here in china ,we could send the goods to them directly ,then they arrange shipping to you .
8. How long should we receive the goods by express ?
DHL/UPS/TNT often takes about 2-5 days ..
9. What's your warranty ?
One year
10. How could we install them after we receive the devices ?
We suggest you to ask professional technicals to install them . There is installation in the manual . If you are familiar with circuit of vehicles ,we could guide you to install them one step by step .
11. How will you provide your after-sales services ?
We will provide 24 hours after-sales services .if you can't get reply online (skype, trademanager, gtalk , yahoo messenger ) in time ,then you could make a call to us directly ,sometimes we left the desk .so can't reply you immediately .,we will provide our mobile phone to all of clients directly .
