Netmate III Mini
Overview
Netmate Ⅲ mini bring a high security monitoring level for uninterrupted power supply(UPS), they designed of a powerful CPU, support USB add-on devices, RS485 add-on(Temp & Humid), also support realize advanced encrypted protocols such as HTTP, HTTPS, SSH, SSL, IPV6, SNMP V3, etc.
Product Function
l Support advantage encryption protocol such as HTTP, HTTPS, SSL, SSH, SNMPV1V2cV3;
l Support telnet, supper terminal, WEB page configuration;
l Compatible with multi-brand and multi-type of UPS;
l Support to add on 2 pieces of Temp&Humid sensors via RS422/RS485 ports;
l Support SNMP trap,E-mail alarm notification;
l Support IPV4/IPV6
l Support scheduled task, remotely control UPS self-testing, switch on/off, battery regularly charge/discharge);
l Support 50000 history events and 5000 data record;
l Comprehensive event handle( including event record and notification);
l Comprehensive managing function( data logs, SNTP and task schedule);
l Support IPV4/IPV6;
l Available to work with centralized software.
Dimension
Ports Introduction
1. Ethernent
2. RS485 port(connect Temp&Humid sensor)
RS485 Definition | |||
1. 485A |
2. 485B |
3. empty |
4. 485B |
5. 485A |
6. empty |
7. +12V |
8. GND |
3. P R/E:LED indicators
4. USB port(connect USB add on device)
5. Gold finger(connect UPS)
Technical Parameters
CPU |
32-bit ARM926EJ-S core 300 MHz high speed processor(CPU) |
|||
RAM |
64Mbyte SDRAM |
Flash ROM |
128M byte and Flash |
|
Network Interface |
10/100Mbps high speed Ethernet self adaptive |
|||
USB |
2 USB 2.0(connect USB add on device) |
|||
Serial Port |
1 RS232 serial port |
|||
1 RS485 serial port for expanding equipment | ||||
SNMP MIB |
Support RFC1213, RFC1628, PPC MIB |
|||
Network Protocols |
TCP/IP, UDP, SNMP, Telnet, SNTP, HTTP, SMTP, DHCP,DNS,TFTP,ARP,ICMP,PPP |
|||
Encrypted Protocols |
HTTPS, SSH, SSL, IPV6, SNMP V3 |
|||
LED Indicators |
Power, Status, Ready, LAN 10/100M Link/Active |
|||
Input(DC) |
8volt - 15volt |
Running Environment |
Temp:0℃~ 70℃ |
|
Power Consumption |
≤2.5W |
Humid:10 ~ 80% |
||
Other Configurations |
System clock for synchronization |
Software Upgrade |
Network Upgrade |
|
Language |
Chinese, English and OEM other language |
|||
System Safety |
Provided based on IP filtering mechanism, and system operation, control and management of the user ID and password protection |
|||
Certificates |
CE/FCC |
|||
Monitoring Interface
<UPS feature>
<communication settings>
(SSL/TLS mail settings)
Accessories
SN |
Name |
M.N |
Function |
Connection |
|
1 |
Temp&Humid Sensor
|
RC77015 OLED Display |
Detect data center indoor temperature and humidity parameters, every 20 M²need to install 1pc |
RS422
|
|
RC77012 Digital Type |
