1:1 Ratio Agricultural Gearbox for Lawn Mower
- 200000 Set / Sets per Month
- Shanghai etc.
- T/T
Product Details
| Place of Origin: | Jiangxi, China | Brand Name: | JCTT | Model Number: | XH50.100Z.01L |
| Gearing Arrangement: | Spur | Output Torque: | 20Nm | Rated Power: | 50HP |
| Input Speed: | 540rpm | Output Speed: | 540rpm |
Product Description
1:1 Ratio Agricultural Gearbox for Lawn Mower
Details:
| Code | Input Power (HP) | Input Speed (r.p.m.) | Gear Ratio (i) | Output Torque (da Nm) | Weight (kg) |
| XH30.192Z.01L | 30 | 540 | 1:1.92 | 20 | 16.4 |
| XH30.147Z.01L | 30 | 540 | 1:1.47 | 16.4 | |
| XH40.192Z.01L | 40 | 540 | 1:1.92 | 23.8 | |
| XH40.192Z.03L | 40 | 540 | 1:1.92 | 23.8 | |
| XH50.100Z.01L | 50 | 540 | 1:1 | 29 | |
| XH50.147Z.01L | 50 | 540 | 1:1.467 | 29 | |
| XH50.169Z.01L | 50 | 540 | 1:1.692 | 29 | |
| XH50.177Z.01L | 50 | 540 | 1:1.77 | 29 | |
| XH50.177Z.02L | 50 | 540 | 1:1.77 | 29 | |
| XH50.215Z.01L | 50 | 540 | 1:1.215 | 29 |
This series gearbox is self-developed. With its characteristics of high universality, simple structure, good performance, etc, it is widely used in garden machines and other agricultural machines.
Quality description:
- ISO9001 Quality System examined & verified by Third Party of CQC and passed second-degree safety quality standardization for machinery manufacturing enterprise.
- Precision forging, cutting by CNC machine, heat treatment by German IPSON & laser techniques .
- Strictly quality control by German CMM.
- Various of gearboxes used in agricultural machines and industrial machines.
- Advanced technics, strong self-development power, able to produce new type gearbox according to customer's design drwings.
