Help CenterSingle Screw Plastic Recycling Extruder
Related Products
Specifications
1.Specical for LDPE HDPE2.Output:250-300KG/H
3.20 years experiences
Product Description:
Single Screw Plastic Recycling Extruder
It is equipped with double hydraulic screen changerand automatic temperature control. The granulating crusher uses adjustable speed motor, pelleting with an extruding machine at the same discharging speed synchronistically. The unit is easy to operate, with a high output, steady performance, and favorable economic benefit.
| ITEM | HXSJ140/140-R | |
| Main Extruder | 1.Screw dia | Ø140mm |
| 2.Screw Length | 3600mm |
|
| 3.Screw L/D | 25:1 |
|
| 4.No of exhauxing hole | Double |
|
| 5.Material for screw | 38CrMoAlA, Quenching and tempering&Nitriding treatment |
|
| 6.Material for barrel | 45Cr, Quenching and tempering&Nitriding treatment |
|
| 7.Gear box | 58#Vertical Gearbox | |
| 8.Main Motor | 75KW-6pole | |
| 9.Motor control means | Start Triangle control means | |
| 10.Heating zone | 7 zones | |
| 11.Heating means | Stainless steel and quartz heater |
|
| 12.Heating power | 48KW | |
| 13.Cooling means | Copper tube with circular water |
|
| 14.Mode of mesh changing | Ø280*280mm double hydraulic screen exchanger |
|
| 15.Die head heating zone | 2 zones | |
| 16.Die head heatin power | 17KW | |
| 17.Die head heating means | With high watt iron-casting heating panel |
| Item | HXSJ140/140-R | |
| Auxi Extruder | 1.Screw dia | Ø140mm |
| 2.Screw Length | 1800mm | |
| 3.Screw L/D | 12:1 | |
| 4.No of exhausting hole | Single | |
| 5.Material for screw | 45 steel | |
| 6.Material for barrel | 45 steel | |
| 7.Gear box | 45#Vertical Gearbox | |
| 8.Main Motor | 30KW-4pole | |
| 9.Motor control means | Start Triangle control means | |
| 10.Heating zone | 2 zones | |
| 11.Heating power | 21KW | |
| 12.Heating means | Stainless steel and quartz heater |
|
| 13.Cooling means | Copper tube with circular water |
|
| 14.Mode of mesh changing | Ø280*280mm double hydraulic mesh | |
| 15.Die head heating zone | 2 zones | |
| 16.Die head heatin power | 11KW | |
| 17.Die head heating means | With high watt iron-casting heating panel |
Peripherics |
1.Cutter | 27 knife alloy blade cutter,frequency control,1.5KW |
| 2.Dewater device | Vertical dewater device,driven power 5.5KW | |
| 3.Storage hopper | Stainless steel square type storage hopper | |
| 4.Hydraulic drive system | Double valve hydraulic station, power 4KW | |
| 5.Funnel | 800*800 stand funnel | |
| Total power | 217KW |
RAW MATERIAL
PLASTIC PRODUCT
QUALITY CONTROL
STORAGE ZONE FOR RAW MATERIAL
DEVELPOMENT TEAM
THE HONOR OF OUR COMPANY
CERTIFICATE
OUR COMPANY
OUR SERVICE:
1.TECHNICAL SUPPORT
2.CUSTMOER TRANING
3.AFTER SERVICE
4.CUSTOMER FILE MANAGEMENT
COMPANY INFORMATION:
Provide technical support to last all lifetime, experience in recycling machine making for 20 years.
Company Name: Huaxing Plastic Machinery Factory Co., Ltd.
Address: Tongyi Industrial Estate, Dongxing Dong Road, Guzhen Town
| Year of Establishment | 1997 |
|---|---|
| Product Range | The main products are venting-type plastic granulator, stepwise venting-type plastic granulator, color-mixing engineering plastic extruding and granulating machine, parallel twin-screw extruder, aluminum composite panel production line and PMMA sheet extrusion line and so on. |
| Capital | US$501 Thousand - US$1 Million |
| Sales Volume | US$2.5 Million - US$5 Million |
| Approvals/Certificates | GMC CE |
| Brand Name | KAI XIN |
| Production Lines | 30lines |
|---|---|
| Factory Size | 25,000square meters |
| Monthly Capacity | 50 sets |
| Investment on Manufacturing Equipments | US$2.5 Million - US$5 Million |
| No. of Staffs | 101 - 500 People |
| No. of R/D Staffs | 11 - 20 People |
| No. of Engineers | 5 - 10 People |
| No. of QC Staffs | 21 - 30 People |
