2015 High Quality Lovol Diesel Generator
- Qingdao China
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | YIDANENG | |
| Model Number | YDNL-22 | Output Type | AC Three Phase | |
| Speed | 1500/1800rpm | Frequency | 50/60HZ | |
| Rated Power | 22kw | Rated Voltage | 230/400V | |
| Rated Current | 39.6A |
Product Description
2015 high quality lovol diesel generator
These generator price select famous Chinese engine brands such as Yangdong, Weifang, Shang Chai, Ji Chai,
which have wide range of power capacity, good starting performance and excellent dynamic performance. These
generator price can provide power electricity for fieldwork, high-rise building,shoping malls, mining oil fields roads
ports and rural places and so on.
| Generator | Genset Model |
| |
| Rated Frequency | 50HZ | ||
| Power Factor | 0.8 | ||
| Rated Voltage | 400/230V | ||
| Rated Power (KW/KVA) | 22/27.5 | ||
| Standby Power (KW/KVA) | 24.2/30.25 | ||
| Phase/Wire | 3Ph, 4Wr | ||
| Overall Size (mm) | 1900×800×1500 | ||
| Weight (kg) | 670 | ||
| Engine | Model | 1003G1A | |
| Type | Closed water-cooled,in line,4-stroke,direct injection | ||
| Rated Power(kw) | 28 | ||
| Intake Type | Natural | ||
| No. of Cylinder | 3.L | ||
| Bore×Stroke(mm) | 100×127 | ||
| Piston Speed (m/s) | 7.62 | ||
| Compression Ratio | 16:01 | ||
| Mechanical Governor Rated | at most 5% | ||
| Electronical Governor Rated | at most 1% | ||
| Noise Level (dBA) | at most 95 | ||
| Exhaust Temperature (℃) | 600 | ||
| Lube Oil Capacity(L) | 8.1 | ||
| Rated Fuel Consumption(L/h) | 7.2 | ||
| Alternator | Model | BCI184G | |
| Rated Power(KW/KVA) | 22/27.5 | ||
| Power Efficiency | 88.60% | ||
| Voltage Regulation | at most ±1 | ||
| Excitation Type | Brushless | ||
| Insulation Class | H |
Company Information
Established in 2000,Weifang Yidaneng Power Co., Ltd.(Weifang Guanghui Agricultural Machinery Co., Ltd.) is located
in Weifang, Shandong Province, which is entitled the " City of Power " in China. YIDANENG is mainly engaged in R&D,
producing and marketing of all kinds of generator sets and water pump sets.
The main products are diesel generator sets, gas generator sets and water pump sets . The diesel engines we select
include both world renowned brands such as Deutz, Ricardo, Steyr and domestic famous brands such as Lovol,Weichai,
Shangchai,Jichai and Yangdong.The diesel gen-sets range is from 6.5kw to 1000kw and is in accordance with ISO9001
quality management system. The gas gen-sets are from 10kw to 500kw, including natural gas gen-sets, LPG gen-sets
and biomass gen-sets.We select famous diesel engines and high quality water pumps to produce automatic water pump
sets, providing water-supply pump unit for fire fighting, automatic water-supply equipment and related control cabinets.
We have our own registered trademark " YIDANENG". The factory covers an area of 36000m³. We have 150 employees,
and divide into production department, technology dapartment, international trade department and other dapartments.All
departments have clear responsibilities, and form the good corporate style and corporate culture.
We mainly supply the below products:
1. Diesel gensets (Open, Silent & Trailer type)
2. Natural gas gensets (Open, Silent & optioanla CHP)
3. Biogas gensets (Open, Silent & optioanla CHP)
- With the jacketed high-pressure fuel pipe, it is safe and reliable.
- It makes the high efficiency and compact space for the seawater pump with the form of great transmission.
- It's safe and stable for electrical system with structure.
- The engines adopt the electrical system which crests the stable governing capability.
- And other departments. All departments have clear responsibilities, and form the good corporate style and corporate culture.
- Since gen-set resached the agreed destination, guaranteed within 12 months or 1500 hours;
- We take charge of all troubles caused by gen-sets fault and repair according to the regulation stipulated by original plants;
- Factors not accordance with the regulation of original plants such as fragile parts, daily consumed components, wrong operating, lack of maintenance are not include in the quality guarantee;
- High performance products;
- Professional technical adviser;
- 1 year or 1500 running hours guaranty;
- Effective after-sales service;
- Free quick-wear parts
.
.
1. What kind of gas can be the fuel of your genset?
--Natural gas (CNG, LNG) or Biogas (Methane gas).
2. What' the MOQ?
--1 set.
3. What kind of package do you use in delivery?
--Less than whole container cargo, plywood case; whole container cargo, naked packing.
4. What's the warranty period?
--1 year or 1500 running hours, whichever comes first.
5. What kind of certificate can you offer?
--ISO, CE
6. Can we customize the genset?
--Yes, we can customize the color and style as your demands.
If you have any other question, please feel free to contact us!
