Specifications
in dynamic modeldigital wiring transmission
display data / time truck no
no zero drift high accuracy
measure axle by axle
Digital wiring Wheel & Axle-Weighing System
Description
This product use aluminum alloy material, with 7 strengthen steel aluminum alloy structure, which can improve the dynamic performance and accuracy a lot . it advantage is the pad thin, light weight, portable .Weighing pad adopts multiple sealing load sensors embedded into the structure of high strength aluminum alloy at the bottom of the weighing pad , high accuracy , good sealing effect.
This product mainly used for dynamic vehicles axle weighing ,it's suitable for road vehicles overload measurement, such as road or traffic police department to overrun or overloaded vehicles weight law enforcement and other fields, but also can be used in the overload warning system of mine or logistics, etc.
Feature
1. multiple load cells are inside weigh pad, an integrated and ultra-slim structure, easy for move, with light weight less than 20kg.
2. With special protection treatment, suitable for harsh environment.
3. patented designed slope can lower force impact from vehicle wheels.
4. double weighting pads can be parallelly connected to measure axle weight .
Application
1. weighing and load control of loading truck in road transportation, construction, agriculture, forestry, and dustbin disposal.
2. weighing of loading truck by executive enforcement units.
3. test weight and center of gravity of aero-plane.
4. weighing automobile wheel and axle load distribution in automobile production line.
5. stability test of special automobile, such as fork-lift truck, crane.
Specification
1. wheel weighing span: 0~20T
Axle weighing range: 0~40t
total weighing span: 0~200T
2. Double LCD display:
Axle weight display: 0~99995kg
Total weight display:0~999995kg
Display unit height: 13mm
dimension: 430×335×190mm
weight: 10kg
128×64 dot matrix display, 16 pages of functional options
24 bit high-conversion ADC, conversion velocity is up to 1000/s
analogue conversion division: 0.5uV
3. Accuracy:
Static: ≤20%F.S ±0.3%F.S
>20%F.S ±0.5%F.S
Dynamic: ≤20%F.S ±1%F.S
>20%F.S ±3%F.S
4. Vehicle velocity: 3~5km/h
5. Use temperature: -10~60℃
6. Relative humidity: <90%
Using show
