Help CenterCarbonated Beverage Plant
Related Products
Specifications
carbonated beverage plant1.beverage machine
2.high quality,favorable price
3.washing,filling,capping in one unit
carbonated beverage plant
PHOTO SHOW
Carbonated Beverage Filling machine is mainly used in the beverage filling operations
operations.
1. The product line is mainly used in washing, filling and sealing carbonated beverage such as carbonated drinks, cola, iced tea and carbonated mineral water and so on.
2. The construction is advanced, . The performance is stable. The operation and maintain are easy. And the speed can be adjusted infinitively and accords with the standards. It is an ideal choice for small and middle scale drink factories.
3. All the line is composed by rotary washer, balanced pressure filler, screw type sealer and conveying sysytem. The capcity is from 3000b/h to 20000b/h.
Model |
DGX |
DGX |
DGX |
DGX |
DGX |
DGX605015 |
Heads of washing, filling, sealing |
14-25 |
18-18-6 |
24-24-8 |
32-32-8 |
40-40-10 |
60-50-15 |
Production capacity(bottle/hour) |
2000-3000 |
4000-5000 |
6000-8000 |
9000-11000 |
12000-14000 |
16000-18000 |
Suitable bottle height |
H=170-320 =50-100 (300-1500ML) |
|||||
Spraying pressure |
0.25-0.3 |
|||||
Power |
4.6 |
5.03 |
6.4 |
8.07 |
9.56 |
11.18 |
Overall dimension(L×W×H) |
2350*1700*2150 |
2830*2030*2030 |
3220*2400*2600 |
3450*2510*2710 |
3800*2800*2710 |
4510*3400*2900 |
Weight |
2500 |
4200 |
5800 |
7000 |
9000 |
12000 |
