Soda Water Filling Machine

Soda Water Filling Machine photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Other, Beverage, Machinery & Hardware
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage, Other, Beverage, Machinery & Hardware
Packaging Type Cartons
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage according to customer
Power 4.6-12KW
Place of Origin Jiangsu, China
Brand Name xiongwang
Model Number DGX
Certification CE&ISO
After-sales Service Provided Engineers available to service machinery overseas

Specifications

soda water filling machine
1.Suitable bottle :PET & Glass
2.Filling Volume(L):250ml-2500ml
3.Capacity 2000-24000BPH

 soda water filling machine

 The Soda Water Filling Machine is mainly used in the beverage filling operations. The three functions of bottle wash, fill and seal are composed in one body of the machine. The whole process is automatic. The machine is used in filling Carbonated Beverages ,Cola.Soda Water n bottles made of polyester and plastics. The machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles. The filling operation is faster and more stable because the micro pressure filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications. The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle -entering chains to adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward steadily and reliably

 Model:

DGX18-18-6

DGX24-24-8

DGX32-32-10

DGX40-40-12

capacity :500ml

6000

8000

10000

12000

bottle shape:

roud or square

PET bottle: (mm)

(Bottle Diameter):φ50-.φ110mm   (Height):150-340mm

cap:

PE srew cap

filling precision:

≤±5mm

filling pressure:(Mpa)

0.15-0.35

0.15-0.35

0.15-0.35

0.15-0.35

rinsing pressure:(Mpa)

0.2-0.25

0.2-0.25

0.2-0.25

0.2-0.25

filling volume :(L)

3.5

4

6

8

overall size:(mm)

2450*1800
*2350

2780*2200
*2350

3600*2650
*2350

3800*2950
*2400

weight: (kg)

3500

4500

5500

6500

 Machine Detail Photo Show:



  soda water filling machinesoda water filling machinesoda water filling machine











 Company View:



 soda water filling machine
