Description
PT124B-219 is shipping or marine or sea water used pressure transmitter , this series can replace Wika (ECO-1) pressure sensor , the material is SS316L for marine , this pressure sensor has been designed for all fields of industrial pressure measurement. With IP65 protection and 316 L seal construction,strong impact resistance, good linearity, long-term stability and repeatability, wide range temperature compensation, corrosion resistance, etc. this pressure sensor typical applications are in the fields of shipping industry, Defense industry, scientific research, Space industry, Petroleum, Chemical industry, Electric power, Ocean and other fields. can replace Wika (ECO-1) brand absolutely .
Feature
SS316L pressure sensor for marine
Various industrial standard signal output
Various electrical connector available
Certain stock for shortening delivery time
High accuracy, free of calibration
One piece stainless steel compact dimension design
can replace Wika (ECO-1) brand
Application
Mechanical Engineering industry
Hydraulic and Level measurement
Gas tank pressure monitoring
Industrial test and control
General Pressure Measurements
marine or sea water
Specification
Name |
shipping or marine or sea water used pressure transmitter |
Model |
PT124B-219 |
Pressure range |
0~1bar~1000bar |
Over load |
150%FS |
Burst pressure |
300%FS |
Output |
4-20mA, 0-5V, 0-10V,0.5-4.5V |
Power supply |
24V(12~36V)DC, 5VDC |
Response time |
<5ms |
Combine error |
0.5% FSO (Including Linearity, Repeatability & Hysteresis) |
Repeatability |
≤ +/- 0.2%FSO |
Long term stability |
≤ +/-0.2%FS/year |
Pressure connection |
M20×1.5,G1/2,G1/4,1/2NPT ( customer tailor ) |
Operating temperature |
-20 °C ~ 80 °C |
Temperature compensation |
0°C ~ 60°C |
Electrical connector |
Hirschman DIN4365 |
Dimension
Order Guide : with "* "are required , with "---"is optional
Our products are widely used in the field of hydraulic pressure, air pressure, petrochemical industry, automotive, air condition and compressor, construction machinery, plastic extrusion, chemical fiber, plastic rubber machine, non-woven fabrics and etc.
ZHYQ has a strong R&D team with more than 10 staffs, there are 3 senior engineers, 5 intermediate engineers, in the major of mechatronics. They have successfully developed a lot of new and High-tech products, won a number of patents and awards.
