Specifications
Mechanical melt pressure gauge1.SS structure, flexible stem
2.local index display
3.small orders are available
4.CE&ISO9000
Mechanical flexible stem melt pressure gauge with display
Description
PT124Y-614 Series mechanical flexible stem melt pressure gauge, adopts the original packaging machine stamen, and designed with all stainless steel structure, isolated diaphragm and local index display. With dial plate’s step-up and stem-down versions, the gauge head can be rotated 360°for unobstructed viewing.
Application
Chemical fiber and filature
Rubber & plastic machinery
The equipment of high temperature steam
Feature
Direct, local reading
Step-up and stem-down version
Customer defined pressure gauge
Install easily, high reliability
Zero adjustment
Specification
Range |
0...10MPa to 0...70MPa |
Accuracy |
±1.6%FS |
Configuration |
Bourdon tube |
Over Pressure |
1.5*FS |
Max Diaphragm Temperature |
350°C |
Dial Diameter |
100mm |
Flexible Length |
0.5...5M |
Process Connection |
1/2″-20UNF, M14*1.5, M18*1.5(Optional) |
Dimension
Ordering guide
| Model | Range(bar) | Snout | process connection | Other requirements |
| * | * | * | * | … |
| Example:PT124Y-612-350Bar-3.33nV/V-6"-1/2-20UNF-6Pin | ||||
| Notes: * is required, … is optional | ||||
