Specifications
Position transducer1China factory fast delivery
2 Proper price1 years warranty
3High accuracy and stability
Magnetostrictive position transducer
Model: ZM-P
Description
ZM-P Series Magnetostrictive position transducer is a new product designed by our company recently, it comes with high speed, reliability and exactly data disposal and communication. It also can supply various output modes, including analog voltage and electrical current, digital output RS485 and so on. It can offer one or more position, and one add temperature output signal. Detailed multifunction output mode to supply the customer with more choices.
Specification
Ranges(mm):80,150,300,500,800,1000,1200,1500,2000,2500,2800,3000,3500,4000,4500,5000(Customer tailor)
Output/supply:A.Analog output 0-5VDC+10%
0-10v/+24VDC+10%
(-5….+5)V/+15VDC+10%
(-10…+10)V/+15VDC+10% or 4-20mA/+24VDC+10%
B. Digital output(RS485); SSI
Operating temp;T1. 0~70°C T2. -25~+80°C T3. -40~+85°C
Storage temp; -40~100°C
Process connector; Thread screw…M18×1.5, M20×1.5, 3/4-16UNF
Flange mounting
Flange material; 1Cr18Ni9Ti
Precision; ±0.05%FS
Error: Better than 0.01%FS
Resolution: 0.01%FS
Hysteresis: 0.01%FS
Thermal affect: +0.007% FS /°C
Zero adjust: 20%FS
Span adjust: ±10%FS
Response time: 0.2~5ms
Application
Servo oil hydraulic cylinder piston position feedback
Servo gas cylinder piston position feedback
Lap machine piston feedback
Non-contact sensing
Reliable and high durability
Protective “G” structure which may endure pressure
High accuracy and repeatability
Absolute position output
Multi-position measurement
Price, Package and Service
1, Our quotation is always valid for you if there is no world market unrest.
2, Receiving your new inquiry, the infos of products & the best price will be provided you asap.
3, Replacement and repair if there is quality problem within 7-15 working days.
4, Port: Shanghai.
5, Payment: T/T.
6, OEM MOQ is more than 100pcs.
7, Delivery time is 7-10 working days.
8, All goods will be fully checked by our QC.
9, Package: The goods will be put into the packing box with instructions and certificate of quality first. Then we pack them into the box with polystyrene foam avoiding the damage to the products.
10, Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder.
