Help CenterHigh Capacity Spoke Style Load Cell Sensor
Related Products
-
Sample and Reliable Spoke Style Load Cell SensorNegotiableMOQ: 10 Pieces -
Alloy Steel/stainless Steel Structure S Type Load CellNegotiableMOQ: 10 Pieces
-
Alloy Steel S Type Tension Load CellNegotiableMOQ: 10 Pieces
-
Alloy Steel Structure Bridge Load CellNegotiableMOQ: 10 Pieces
-
Alloy Steel Bridge Type Load CellNegotiableMOQ: 10 Pieces
Specifications
spoke style load cell1.alloy steel/ alluminum alloy
2.sample and reliable
3.easy to install and use
4.CE&ISO9000 certified
High capacity spoke style load cell sensor
Description
1,material:alloy steel/alluminum alloy steel
2,spoke style
3,cost effective
4,high capacity
5,high precision
6, easy to install and use
Application
Electronic platform scales, truck scales, railroad track scales, hopper scales, etc.
Parameters
Rated Load(t) |
500(KG), 1, 2, 3, 5, 10, 20, 30 |
|||
Precision |
C1 |
G1 |
Insulation Resistance(MΩ) |
≥5000(100VDC) |
Composition Error(%F.S) |
0.05 |
Excitation Voltage(V) |
9~12(DC) |
|
Rated output(mv/v) |
2.0±0.04 |
Compensated temp.Range(°C ) |
-10~+40 |
|
Non-linearity(%F.S) |
0.05 |
0.1 |
Use Temp. Range(°C ) |
-35~+65 |
Hysteresis(%F.S) |
0.05 |
0.1 |
Temp.Effect on Zero(%F.S/10°C) |
0.03 |
Repeatability(%F.S) |
0.03 |
0.05 |
Temp.Effect on Span(%F.S/10°C) |
0.02 |
Creep(%F.S/30min) |
0.02 |
0.1 |
Safe Overload (%F.S) |
150 |
Zero Balance(%F.S) |
±1 |
Ultimate 0verload(%F.S) |
200 |
|
Input Resistance(Ω) |
730±4 |
Defend Grade |
IP65 |
|
Output Resistance(Ω ) |
700±3 |
Cable (4PIN) |
3-5m |
|
Dimensions
