Anti-jamming Digital Temperature Indicator

Specifications

Anti-jamming digital temperature indicator

Description

 1.N60/N50/N10 digital temperature indicator is the new developed product of our company. It has much advanced technology in the world ,such as the technology in electron, singlechip, computer erasure, anti-jamming and so on.

2.To make the indicator have the strong point of high precision of measure and control,as well as the well fuction of anti-jamming.The whole machine has three cases of 96*96*100(N60)/ 96*48*100(N50) 48*96*100 (N10). So it is small in volume, light in height and save power and completed function and reliable task and easy to use.

3.It can be widely used not only in situation of display and autocontrol in hydraulic pressure, oil, plastics, latex, printing and dyeing, textile industry but also can be compound with resistance strain guage press sensor of other manufactory.

4.If it is used with our model PT124- series melt pressure transducers and normal pressure transducer. As high precision pressure of measure and control, it can be set upper limit and lower limit alarm.It has the indicator light on alarm,relay touch output control peripheral equipment, high precision of voltage output module, current output module and relay output control modult for user to choose.The machine adopts the operation of humanism,so it is easy for operating.

.

Specification

(1).display                                      double four digits high brightness green and red radiation numeral pipe

(2).display exculpation rate            0001

(3).the range of display                  0001-9999Mpa (radix point alterable)

(4).the precision of metre               0.2%FS+-1bit digital temperature indicator

(5).the display of indicator light      adjust indicator light,OUT output indicator light,AL1,AL2 alarm indicator light

(6).Pressure signal input                2mV/V ;3.3mV/V (Optional)

(7) Temperature signal input          K,J,E thermocouple optional digital temperature indicator

(8).sampling speed                         20 times/second

(9).sensor operating voltage          9V high precision DC

(10).output control                          the pressure or electric current output with full singal rult

(11).main alarm output                   upper limit alarm has relay output (220V 1A) upper limit alarm display (out)

(12).assistant output                      assistant output can be compound with different function module and set by the meter to meet the difference output need.The content in detail please read 1(3)the explain of module function.Assistant output can be choosed from.(order for explain)

(13).the range of alarm                  0001-9999Mpa (radix point alterable )

(14).Calibration display                  display 80% of full ranges (the sensor should be no load) CAE light

(15).the temperature and humidity of work             0-55’C, ≥80%RH

(16).power demand                        85-265VAC 50Hz-60Hz

(17).exterior size                             N60: 96mm x 96mm x 100 mm (W x H x D) ;

                                                       N50: 96mm×48mm×100 mm (W x H x D)

                                                       N10: 48mm×96mm×100 mm (W x H x D)

(18).placket size                             N60: 96mm x 96mm x 100 mm (W x H x D)

                                                       N50: 96mm×48mm×100 mm (W x H x D)

                                                       N10: 48mm×96mm×100 mm (W x H x D)

(19).itsele height                            approximately 400g/200g/200g

Dimensions

                                                                                   N10

Maintenance

1.Meter can operate in the environment of 0-55°C,relative humidity <=80%RH,no dust and no corrosive gas.

2.free repair for quality warranty since the date of ex-factory. If the damage by customer or the date has exceeded the warranty period, then we will charge appropriately.

FAQs

1. What's your MOQ?

 We have no limits about MOQ, we can sell product to you even you just want 1 piece.

2. How long is the warranty?

We offer 12 months warranty for any quality problems of the product itself.

3. What terms of payment are available?

 TT, Western Union and Money gram.

4. How about the usual delivery time?

We will send goods to you within 15 working days.

5. What detailed information do we need to provide if we want to purchase an order?

 Pressure range, output, accuracy, pressure connection and other related parameters.

6. Does quantity affects price?

Of course. For larger quantities, we will give you some discount. But small quantities are also welcomed.

Company profile

We ZHYQ is the leading manufacture which specializes in the design and construction of various transducer, transmitter and automation control products for more than 13 years. Our main products contain melt pressure transmitter, pressure transmitter, automotive pressure sensors, pressure gauge, temperature transducer and pressure instrumentation. We service the markets of Industrial, Oil & Gas, Automation Control System, Plastics, Rubber, Composites and etc.

With the development strategy of offering High-tech, High Quality, High level service to every customer, we successfully passed ISO9001 (2008) and CE Certificates. What’s more, our products are highly welcomed in Asia, America, Europe, Africa,  etc.

Your requirement is our creating power; your satisfaction is the greatest reward and confirmation to us. And we’ll make persistent efforts to improve our technology and service to meet your needs!
