Specifications
Ceramic sensor chip1.high elasticity
2.small orders are available
3.CE&ISO certificates
rrosion & abrasion resistance
Ceramic pressure sensor chips
Description
PS-10 Series ceramic sensor chip is a dry-type ceramic piezoresistive sensor chip by special technology. Ceramic is a recognized material of high elasticity, corrosion & abrasion resistance, strong shock and vibrant resistance. The thermal stability can make its operating temperature up to -20~80°C, It achieves high accuracy, high stability. Electrical insulation >2kV, strong output signal, excellent long-term stability.
Application
PS Series ceramic sensor chip has been widely used in the process control, environment control, hydraulic pressure and pneumatic equipment, servo valve and drive, chemical products, chemical industry, medical instrument, and other fields. With the characteristic of small dimension, 18 mm diameter, 6.35 mm thickness, 2~200bar range, high performance-price ratio, it has been widely used in various pressure-measuring occasion.
Feature
Solid ceramic sensitive film pressure sensor chips
Full-range laser calibration pressure sensor chips
Excellent corrosion & abrasion resistance performance
Strong shock resistance pressure sensor chips
High accuracy & high stability pressure sensor chips
Wide-range operating temperature
Smart volume, easy for encapsulation pressure sensor chips
Specifications
Excitation |
5 ~ 30VDC pressure sensor chips |
|
Bridge resistance |
10K±20% |
|
Range |
0~2bar~200bar pressure sensor chips |
|
Response time |
<1mS ceramic chip |
|
Combined accuracy |
0.1 ~ 0.3 FS% (Including linearity , hysteretic, repeatability) |
|
Zero output |
0±1mV/V @ 25°C |
|
Sensitivity |
1.4 ~ 4.8 mV/V |
|
Temperature characteristic |
±0.05%FS/°C pressure sensor chips |
|
Stability |
<0.2%FSO/year |
|
Operating temperature |
-40-125°C |
|
Insulation |
>2 KV |
|
Dimension |
18*6.35mm |
|
Assembly of ceramic sensor
Unit:Bar
Rated range |
2 |
5 |
10 |
20 |
50 |
100 |
200 |
Over pressure safety |
4 |
10 |
20 |
40 |
100 |
20 |
400 |
Burst pressure |
7 |
15 |
35 |
70 |
150 |
150 |
450 |
Ordering instruction
minimal order quantity |
1 piece |
warranty |
12 months |
payment |
T/T, western union, moneygram |
OEM service |
acceptable |
delivery time |
within 7 working days |
package |
standard packing or as your requirement |
Company profile
We ZHYQ is the leading manufacture which specializes in the design and construction of various transducer, transmitter and automation control products for more than 13 years. Our main products contain melt pressure transmitter, pressure transmitter, automotive pressure sensors, pressure gauge, temperature transducer and pressure instrumentation. We service the markets of Industrial, Oil & Gas, Automation Control System, Plastics, Rubber, Composites and etc.
With the development strategy of offering High-tech, High Quality, High level service to every customer, we successfully passed ISO9001 (2008) and CE Certificates. What’s more, our products are highly welcomed in Asia, America, Europe, Africa, etc.
Your requirement is our creating power; your satisfaction is the greatest reward and confirmation to us. And we’ll make persistent efforts to improve our technology and service to meet your needs!
