Specifications
three die-cutting Flexo Printing Machine1.with slitting,crossing,die cutting position
2.high printing precision
5 Colors three Die Cutting Station Flexo Printing Machine
Performance characteristics:
1.Main motor adopts imported frequency stepless speed regulator.
2.Unwinding, traction and rewinding are controlled by magnetic powder arrester, clutch and tension inspector. Tension controller is automatic type.
3.Machine adopts ceramic veins roller, which is characterized by wearable,rust-resistant and long using life, etc. It can improve the printing efficiency.
4.printing unit adopt plate register function, each veins roller can print independently, without effecting others when leave it alone.
5.Each printing unit collocated with IR dryer, the UV dryer is optional.
6.The ink roller can break away automatically when machine stops, and it still run in a low speed avoid the ink dry or asymmetric.
7.Unwinding and rewinding shaft adopt air shaft, it's convenient to change load and unload the material.
8.From material-feeding, printing, drying, glazing, laminating, molding,die-cutting, rewinding to waste-collecting can be done in the same machine, the machine is known for machine characteristics such as wideprinting range, environmental ink, fast printing speed, convenient operation, high economic benefit and so on. It's the best choice for note, paperboard and label printing factories...
Suitable material |
Roll material such as paper, plastic, film, etc. |
Printing colors |
2-6 (colors ) |
Printing width |
320mm |
Printing length |
142-320mm |
Machine speed |
70m/min |
Printing speed |
15-60m/min |
Overprint precision |
±0.1mm |
Unwinding diameter |
φ600mm |
Rewinding diameter |
φ500mm |
|
Unwinding diameter of lamination
|
φ210mm |
