High Quality Plastic Thermoforming Machine
Multi-functional Thermoforming Machine
1.CK-660C MULTI-FUNCTIONAL THERMOFORMING MACHINE is designed with most advanced thermoforming technology, a combination of mechanical, electrical and pneumatic components. 2.And the wholesystem was controlled by PLC.
3.The machine has man-interface operation which Electric cooker constant temperature ,preheat,sends sheet by chain,running by cam, forming by up and down mould and cutting by mouldknives.
4.It combines the sheet sending, heating, stretching, forming,cutting into one process.
5.The machine is suitable for PP, PS, ABS, HIPS,PEP material.
6.They are widely used in producing disposable table wares as various kinds of cups like ice cream cups, milk cups, jelly cups, cup covers, instant noodle bowls, toy boxes, etc.
7.It can also be used inplastic package in medicine manufacturing, light industry.textile,
tourism, etc.
Technical Parameters
Suitable material |
PP,PS,HIPS,PET,PVC |
|
Using power |
3x380V+N+PE,50HZ |
|
Suitable thickness of sheet |
0.35-2.2mm |
|
sending motor power(Japan Yaskawa) |
2.4-4.4kw |
|
Air consumption |
2600L/min |
|
Machine weight |
4.0/4.5T |
|
Max.forming area |
640x330 |
|
Max.depth of forming |
160-180mm |
|
Adjustable length of the trip |
100-400mm |
|
Productivity efficiency |
20-35times/min |
|
Rated heating power |
67-78kw |
|
Regulator pressure mould heating |
50A |
|
Main machine motor power |
7.5kw |
|
Water consumption |
100L/min |
|
Dimension |
3300x1650x2250mm |
|
Suitable width of sheet |
500-630mm |
|
Using pressure |
0.8Mpa |
|
FAQ:
1.Q:Why choose us?
A:We are China Leading manufacturer. We are confident that with our experience in coating machine production line , quick delivery time, excellent quality and comprehensive superior service we can give our customers complete satisfaction.
100% QC inspection before shipping.
2.Q:What's your MOQ ?
A:Generally if you choose the different products,our minimum order qty.also will be different.
3.Q:Delivery time:
A:The goods need 15-45 days to be made after receive deposit.
4.Q:What's your payment and payment method
A: Normally we choose in T/T
5.Q:Where is your sea port ?
A: We ship from ningbo or shanghai port.
Our Promise:
Customers satisfaction, provide good quality and reasonable price be to engaged in 100% of us.
24 hours online service.
We always say OK to my customer.
The above product photos are coming from main production.
Thanks and the first cooperation to be expected.
If you interest,please feel free to contact us now!
