Pole Coating Machine

Name: Pole Coating Machine
Brand: Jiangnan
SKU: 130528763
Availability: InStock

US$ 10,000 - 80,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Other, Machinery & Hardware

Automatic Grade:

Automatic

Ruian Jiangnan Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo \Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, Machinery & Hardware

Automatic Grade Automatic

Driven Type Electric

Power 130KW

Packaging Type Cartons

Packaging Material Metal

Place of Origin Zhejiang, China

Brand Name Jiangnan

Model Number TB

Specifications

pole coating machine
1. Changeable coating methods
2. Energy-saving drying system

pole coating

machinemain parameter:

Whole machine controlled by PLC
Tension controller adopts Mitsubishi
Main motor adopts ABB motor .
The dry oven length is about 18 meters
Machine speed is about 180mmin
Coating speed is about 160mmin
Coating mode depends on the coating thickness, the solid content and the viscosity .
Heating type :Electric heating ,Oil heating ,Steaming heating (You can choose one which is most economically )...

Model	TB200 - TB 500
Coatingwidth	200mm-500mm
Material	copper foil , aluminium foil
Unwinding dia.	φ300~600mm
ewinding dia.	φ300~600mm
Oven temperature	30 ~ 220°C(According to the material)
Oven length	3 ~ 48 m (According to the material)
Coating speed	5~ 10 m/min (According to the material)
Coating type	Comma scraper coating, veins roller coating, three-rollers coating, etc.
Heating tyope	Electric heating
