Specifications
This machine adopts frame structure type and length of machinecan be determined by the user.
Performance characteristics:
1.This machine adopts frame structure type and length of machine can be determined by the user.
2.AC frequency stepless speed regulation, pre-traction, coating, laminating traction, rewinding, ect. are synchronously controlled.
3.PLC control with man-machine interface can achieve many advantages such as precisenesss, sensitivity, easy-operation, anti-jamming.
4.Coating types can be different according to different requirements,such as comma scraper coating, metering roller, veins roller, stick coating and air bells doctor, ect.
5.This machine adopts separately constant temperature drying system and various kinds of heating types, such as hot air cycling heating,IR heating, ect; automatically controlling temperature in each
temperature zone, adjustable cycling in-out air system.
6.Inner leading roller of oven adopts double gilde assembing type and drives with main machine synchronously; oven adopts door-opening on two sides or air cylinder pushing opening, operation platforms and defence grilles on both sides.
7.Auto counting, auto rising and decreasing speed, auto tape-broken inspection, auto error, alarm,pneumatic components auto on-off.
8.Rewinding and unwinding adopt double working positions turning type or single working postion hydraulic pressing lift-drop type,materials loading&unloading by air shafts.
Technical Parameters
Model |
Tb300 Tb600 Tb800 Tb1000 Tb1100 Tb1300 Tb1600 TB1600+ |
Coatingwidth |
300mm 600mm 800mm 1000mm 1100mm 1300mm 1600mm 1600+mm |
Material |
Roll material such as film, Paper, Cloth, Foil, etc. |
Unwinding dia. |
φ300~800mm φ300~1500mm |
ewinding dia. |
φ300~800mm φ300~1500mm |
Oven temperature |
30 ~ 220°C(According to the material) |
Oven length |
3 ~ 48 m (According to the material) |
Coating speed |
10 ~ 150 m/min (According to the material) |
Coating type |
Comma scraper coating, veins roller coating, three-rollers coating, etc. |
Heating tyope |
Electric heating, steam heating, oil heating, etc. |
