High Tension Hot Dipped Galvanized Steel Wire Binding Wire
1.Produce of High Tension Hot Dipped Galvanized Steel Wire Binding Wire
Steel rod coil-wire drawing-wire annealing-rust removing-acid wasting-boiling-drying-zinc feeding-wire coiling
- Wire Rod(low carbon steel, ISQ195, ASTM,SAE 1006/1008)
- Wire Drawing(draw 6.5mm wire to 4.mm or other diameter, two types of drawing methods)
- Annealing(wire go through the high temperature, improve T/S, preparation for the zinc coating)
- Zinc coating(electro GI wire and hot-dipped GI wire, dealed with electro polish and high temperature. More zinc coating, the better resistance of corrosion)
- Wire Coiling(Weight of coil/roll: 200kg, 100kg, 50kg, 25kg, 10kg, 2-8kg)
Galvanized iron wire is made with mild steel, hard-drawn, and then galvanized. It is rust-resistant, and very versatile in applications. Galvanized iron wire can be supplied in the form of coil wire, spool wire or further processed into straightened cut wire or U type wire.
Annealing is the key determinant of the wire T/S
2.Processing of High Tension Hot Dipped Galvanized Steel Wire Binding Wire
Hot dipped galvanized wire from choiced low carbon steel wire, through the strict process of Wire Drawing---Annealing---Acid Washing---Water Clearing---Drying---Galvanizing--Coiling, in this way, excellent flexibility and tensile strength could be guaranteed.
3.Technical and Mechanical Characters of High Tension Hot Dipped Galvanized Steel Wire Binding Wire
Material: Q195/235 low carbon iron wire
Wire Diameter: 0.7mm-4.9mm
Zinc Coating: Commercial grade: 30-60grams/sq.m
Heavy coating: >=100grams<=300grams/sq.m
Tensile Strength: 350-550Mpa
Detailed Specifications:
HS code |
Product name |
Wire dia. |
Allowed tolerance |
Zinc coating |
Packing |
72172000 |
Hot dipped galvanized iron wire |
0.2-0.3mm |
±0.01mm |
40-60g/m2 |
4kg/spool |
0.3-0.6mm |
±0.01mm |
40-60g/m2 |
10kg/coil |
||
0.5-1.6mm |
±0.02mm |
70-90g/m2 |
25kg/coil |
||
1.3-8.5mm |
±0.02mm |
240-360g/m2 |
50kg-800kg/coil |
Packaging and shipping of High Tension Hot Dipped Galvanized Steel Wire Binding Wire
Weight of coil/roll: 200kg, 100kg, 50kg, 25kg, 10kg, 2-8kg
Packaging: Plastic film inside, Hessian or woven bag outside or as require
Inner with plasic film and outside with weaving bags
Inner with plastic film and outside with gunny
Container Shipping:
Anything We can do for you, please contact us as soon as possible !
