1000W Wind & Solar Hybrid Controller

1000W Wind & Solar Hybrid Controller thumbnail-1
1000W Wind & Solar Hybrid Controller thumbnail-2
1000W Wind & Solar Hybrid Controller photo-1
1000W Wind & Solar Hybrid Controller photo-2
US$ 218 - 228 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
GT
Model Number:
GTWS
Contact Supplier Request Quote Chat Now
Zhangjiagang Great-Trust Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name GT
Model Number GTWS
Application Solar System Controller
Rated Voltage 48V
Maximum Current 13A

Specifications

1.Decent appearance
2.Easy operation
3.Visual LCD display
4.Perfect protection functions
5.Meet CE standard


 GTWS  1000W Wind Solar Hybrid Controller



1.Introduction

The wind/solar hybrid controller is specially designed for high-end small-scale wind / solar hybrid system and especially suitable for wind/solar hybrid street light system and wind / solar hybrid monitoring system. The controller can control wind turbine and solar panel at the same time and transform the wind and solar energy into electricity for DC load use,  with excess energy stored into batteries.



2. Performance features

2.1Superior military-grade components to ensure the product stability.

2.2Perfect protection function, thus the system has higher reliability.

2.3Check and set all operation parameters as requirement from LCD display.

2.4Voltage limiting and current limiting charge mode ensures battery in the best charging status.

2.5Two DC Load output, light control, time control, constant output, and multiple output control mode selections.

2.6PWM stepless dumpload mode, releasing excess power into dumpload, making battery charging in best status.

2.7Design of high quality aluminum alloy appearance, with small size and good cooling effect.



3. Certifications



Small and medium-sized S&T enterprise technology innovation fund project approval



Anhui province high and new technology product certification



Utility patent of strong wind resistance, step less dump load wind power controller



Utility model patent for integration of rectification and dump load of wind power main circuit board



“Industrial Products Quality Supervision and Inspection Center Test Report” from Posts and Telecommunications



Ministry of Information Industry.



European CE certification.



Appearance design patent certification



4.Technical data



Product Model

GTWS10-24-N00

GTWS10-48-N00

Rated Battery Voltage

24V

48V

Rated Wind Turbine Input Power

1kW

1kW

Maximum Wind Turbine Input     Power

1.5kW

1.5kW

Wind Turbine

Brake Current

42A

21A

Rated Solar Input Power

300W

300W

Floating Charging Voltage

29V

58V

Display Mode

LCD

Quiescent Current

≤20mA

Ambient Temperature & Humidity

-20~+55°C/35~85%RH(Without Condensation)

Communication Mode (Optional)

RS232,RS485,RJ45,GPRS (optional)

Temperature Compensation          Function (Optional)

-4mV/°C/2V ,–35°C--+80°C ,Precison:±1°C

Dimension

(L x W x H)

445×425×170mm

Net Weight

11kg

In order to serve our customers better. Our company can adjust parameters configuration according to  customer’s requirement.



  5.Optional Functions



OPTIONAL FUNCTIONS

OPTIONAL ACCESSORIES

·Temperature compensation function

·Ethernet communication module

·Wind turbine low voltage charge function

·GPRS communication module

·RS communication function

·SD storage card

·SD card function

·RS485-USB converter

·Wind speed detection function

·RS485-RS232 converter

·Wind turbine rotate speed detection function

·RS232-USB converter

·Wind turbine micro current charge function
