CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct

Jiangyin Spark Electronic Technology Co., Ltd.
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct thumbnail-1
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct thumbnail-2
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct thumbnail-3
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct thumbnail-4
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct thumbnail-5
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct thumbnail-6
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct photo-1
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct photo-2
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct photo-3
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct photo-4
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct photo-5
CE 30A/0.333V Mini Inner Door Current Transducer Clamp ct photo-6
US$ 2.5 - 39 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
JIANGYIN SPARK
Model Number:
XH-SCT-T06/T10/ T16/ T24/36
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name JIANGYIN SPARK
Model Number XH-SCT-T06/T10/ T16/ T24/36
Usage Other, Electronic, Consumption Sensor
Phase Single
Coil Structure Toroidal
Coil Number Autotransformer

Product Description

Feartures Of 30A/0.333V CE split core current transducer clamp ct
Features:
Small size, low cost
High secondary turns
Secure locking hinge

Features:
Maximum continuous primary current 5A to 5000AAC
Current Ratio: 3000: 1
Output: 0.333V, mV or mA.
Accuracy: ± 1% from 5% to 120% of rated current
Insulation Voltage: 600VAC
Maximum Primary Voltage: 5000VAC(Insulated Conductor)
Phase angle: Less than 2 degrees at 50% of rated current
Frequency Range: 50 Hz to 400 Hz
Operating Temperature: -15C to 60C.
Leads: 4Foot(105cm), UL 1015, Twisted Pair, 0.34 mm2(22AWG)
CE recognized, and RoHS compliant
Output and leads can be customized



Drawing Size Of 30A/0.333V CE split core current transducer clamp ct

Model

I.D.

Ratio

Rated Amps

Accuracy

XH-SCT-T06

6mm

1000:1

1, 5,10, 15, 20,

0.5 , 1.0

XH-SCT-T10

10mm

3000:1

5, 15, 30, 50, 75,80

0.5 , 1.0

XH-SCT-T16

16mm

3000:1

50, 70, 100, 120

0.5 , 1.0

XH-SCT-T24

24mm

3000:1

100, 150, 200, 300

0.5 , 1.0

XH-SCT-T36

36mm

3000:1

300, 400, 500, 600

0.5 , 1.0

 CE 30A/0.333V mini inner door current transducer clamp ct



Pls contact me for much more information by Skype

My Skype:paul.duke188





CE 30A/0.333V mini inner door current transducer clamp ct



Our products



CE 30A/0.333V mini inner door current transducer clamp ct



Strong items



CE 30A/0.333V mini inner door current transducer clamp ct



Certifications



CE 30A/0.333V mini inner door current transducer clamp ct



Quality Control



CE 30A/0.333V mini inner door current transducer clamp ct



Package Of 30A/0.333V CE split core current transducer clamp ct



CE 30A/0.333V mini inner door current transducer clamp ct



Transportation





CE 30A/0.333V mini inner door current transducer clamp ct



Contact detail



CE 30A/0.333V mini inner door current transducer clamp ct
