200A/66.67mA Ring Core Current Transformer(split Core Current Transformer) Outdoor
- shanghai
- Money Gram
You May Like
-
CE UL ISO SGS Split Core Current Transformer 0.33v/ 0.1667V
-
5A 1Aoutput Split-core Current Transducer ce 100/5A 1000/5A
-
SCT-019 0.75" Window Size Single Phase Mini Split Core Current Transformer 333mV Secondary
-
0-3000A/0.333v Split Core Current Transformer
-
XH-SCT-0750 333mV Split Core Current Transformer
-
Toroidal Ferrite Split Core Current Transformer for Energy Meter
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Jiangyin Spark | |
| Model Number | t10 t16 t24 t36 |
Product Description
plit-Core Current Transformer XH- SCT-25
Φ25mm Opening With 50 To 400 Amp Rating
Description
XH-SCT25 Series are split-core current transformers. The CT can be
mounted to existing panels, such as control centers or load centers, to
measure or monitor wattage. These CTs can be mounted without removing
existing cables for easier installation
Specifications
Rated Current 50A to 400A
Normal Current Output: 20mA, 40mA, 66.6mA,100 mA
Normal Voltage Output: 0.333V
Opening Dimension:25mm
Insulation Voltage:600Vac
Withstand Voltage: 2500V/0.3mA/3S
Accuracy:Class ±0.5%
Operating Temperature: -40 C- 85 C
RoHS Compliant
Frequency Range:50-400Hz
Leads:4Foot(105cm),UL 2464
Weight: 150g
Output and leads can be customized
Applications:
Sub-Metering Accurate Measurement
Data Loggers to analyze Building & Machinery Performance
Digital Fault Recorders
Smart Grid Application Features ,Load Center
Three Phase Balance Control
In-Factory Display ,In-Home Display
Inverters for Solar & Wind Turbine Systems
Power Measurement Device For PLC
Our main products:
Split Core Current Transformer, Split Core Current Sensor, Split Core Current Transducer, Clip on Current Sensor, Current Transformer Manufacturer, Split Core Cts Manufacturer, Current Sensor Manufacturer, Clamp on Current Transformer, AC Split Core Current Transformer, Flex Core Current Transformer
Drawing size
If you are interested in flexible rogowski coil, pls click.
